64-channel A-Series package, optoelectrode, cabled, epoxy
OXA64LP carries 64 channels to 2 Samtec 40-pin connectors, over a thin-film cable to a PCB carrying the connectors, in epoxy.
An A-Series package mounts a silicon probe on a rigid printed-circuit interconnect that ends in a standard connector, for acute and intra-operative recording and stimulation, most often in mice and small animals.
Records and stimulates in acute and intra-operative preparations. Optical stimulation runs from a separate laser or LED source. Needs an adapter to reach a standard Omnetics headstage. Mates with a Samtec 40-pin on the headstage side. Available as a fully assembled probe assembly.
OXA64LP
4 specs
| Channels | 64 |
|---|---|
| Connector | Samtec 40-pin ×2 |
| Construction | Cabled: thin-film cable to the connector PCB |
| Protective covering | Epoxy |
