Packages · CM Package
MRCM16LP
Built for the MR scanner: no ferromagnetic parts in the assembly
MRCM16LP carries 16 channels to an MRI Omnetics 16-pin connector, with the probe bonded to a PCB carrying the connector, in epoxy.
A CM package mounts the connector directly on the probe assembly with no interconnect cable, which keeps the footprint small and the weight low; it is the usual chronic package for a mouse.
Small and light: for chronic implants, typically in mice. Built without ferromagnetic parts for use in or near an MR scanner. Mates with an Omnetics 16-pin on the headstage side. Available as a fully assembled probe assembly.
SKU pkg_cmm--mrcm16lp · Packages in the webstore
Specifications
| Channels | 16 |
|---|---|
| Connector | MRI Omnetics 16-pin |
| Construction | Direct-bond: probe bonded to the connector PCB |
| MRI-conditional | Yes |
| Protective covering | Epoxy |
