Packages · Activus Package

AVH256

256Channels
1Connectors
Part no.AVH256
Contents

256-channel Activus package, 35.92 mm cable

AVH256 carries 256 channels to a Micro HDMI connector, over a 35.92 mm thin-film cable to a PCB carrying the connector, in a 3D-printed polymer case.

An Activus package integrates the digitizing headstage chip into the probe package: the silicon probe is passive and an Intan RHD chip on the package amplifies, filters and digitizes every site, so no separate headstage is mounted and the cable out of the package is digital.

The probe stays passive; a discrete headstage chip in the assembly digitizes at the head. Cable length 35.92 mm; other lengths available. Mates with a Micro HDMI on the headstage side. Available as a fully assembled probe assembly.

Also known as

AVH256 · AVH256_1 · AVH256_2

AVH256SKU pkg_avx--avh256

5 specs

Channels256
ConnectorMicro HDMI
ConstructionCabled: thin-film cable to the connector PCB
Cable length35.92 mm (other lengths available)
Protective covering3D-printed polymer case
