64-channel CM package
SEACM64 carries 64 channels to a Samtec SEAF8 80-position connector, with the probe bonded to a PCB carrying the connector, in epoxy, at 1.26 g.
A CM package mounts the connector directly on the probe assembly with no interconnect cable, which keeps the footprint small and the weight low; it is the usual chronic package for a mouse.
Small and light: for chronic implants, typically in mice. Weighs 1.26 g. Mates with a Samtec SEAF8 80-position on the headstage side. Available as a fully assembled probe assembly.
SEACM64
5 specs
| Channels | 64 |
|---|---|
| Connector | Samtec SEAF8 80-position |
| Construction | Direct-bond: probe bonded to the connector PCB |
| Protective covering | Epoxy |
| Weight | 1.26 g |
