Packages · Vector Package

V16

16Channels
1Connectors
Part no.V16
Contents

16-channel Vector package, 70 or 110 mm cable, Omnetics 16-pin

V16 carries 16 channels to an Omnetics 16-pin connector, over a 70 or 110 mm thin-film cable to a PCB carrying the connector, in a 3D-printed polymer case.

A Vector package mounts a Vector Array, 16 to 128 channels on a 70 or 110 mm support shaft, and terminates in Omnetics or Hirose (ZIF-Clip) connectors, for deep targets in large animals; the chronic builds are configured to an implantable length for a chamber and microdrive.

Built for deep-brain targets in large animals; chronic builds configure to an implantable 30 to 55 mm. Cable options 70 or 110 mm. Mates with an Omnetics 16-pin on the headstage side. Available as a fully assembled probe assembly.

Also known as

V16

V16SKU pkg_vec--v16

11 specs

Channels16
ConnectorOmnetics 16-pin
ConstructionCabled: thin-film cable to the connector PCB
Cable length70 or 110 mm
Protective covering3D-printed polymer case
Total length70 mm or 110 mm
Silicon electrode length10 mm standard; 12 and 15 mm designs available
Site area177 µm² standard; 121 µm² on the tetrode designs
Site coverage375–6,300 µm
Support body diameter315 µm OD
Site materialIridium (SIROF available)
V16SKU pkg_vec--v16

The configurations this part comes in. You choose it on the probe or grid datasheet when you order.

5 options

Configure

Build
All
V16_100-200
V16_100-50
V16_115-50
V16_60-200
V16_60-50

Your selection

V16 (V16_100-50)
Build: V16_100-50
SKUpkg_vec--v16_cl100_50
Ordered as part of a probe assembly

Options

5 of 5
