Neural Probes · Matrix Array Series

4-Shank 32-Channel Probe, 2 mm

32Sites
4Shanks
2mmShank Length
12.5µmSite Pitch
Part no.M4x8-Poly3-2mm-25s--200-177
Contents

32-site Matrix array, 4 shanks, 2 mm, 177 µm², 12.5 µm pitch, 200 µm apart

Four short shanks side by side, closely spaced for coverage within one structure, with sites staggered in three columns so neighbouring sites see the same units. Among the 369 probe designs in the design space it is in the lower quartile: 32 sites (a common choice — 158 of 369), 2 mm shanks (8th percentile of the 366 measured), a 0.06 mm-deep site array (6th percentile), 749 sites/mm² (79th percentile) and a 0.33 mm³ neural interface (17th percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The short shanks suit superficial targets.

Orders as a probe-plus-package assembly, in 19 package configurations, 2 of them microdrive-compatible. Built for the Matrix Array platform: this 2D array installs in a Matrix package slot and is not assembled in other packages. Silicon 50 µm thick. Z-coat not available on this close-spaced poly layout. Research use only.

Also known as

m4x8_poly3_2mm_25s__200_177

4-Shank 32-Channel Probe, 2 mmSKU prb_mtx--m4x8_poly3_2mm_25s_200_177

15 specs

PlatformMatrix Array (one 2D array per platform slot)
Channels32
Shanks4
Shank length2 mm
Shank separation200 µm
Site layoutPoly3
Site area177 µm²
Site pitch12.5 µm
Vertical span65 µm
SubstrateSilicon
Site materialIridium
Thickness50 µm
Neural interface volume0.327 mm³ (higher than 17% of 369 designs)
Site coverage density749.0 sites/mm² (higher than 79% of 369 designs)
Brain coverage density97.8 sites/mm³ (higher than 87% of 369 designs)
4-Shank 32-Channel Probe, 2 mmSKU prb_mtx--m4x8_poly3_2mm_25s_200_177

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

19 options

Configure

Compatible Package
All
MA128_W — 128-ch Omnetics
MA128_Y — 128-ch Omnetics
MA64 — 64-ch Omnetics
MAVH128_SP — 128-ch
MAVH128X2_SP_P — 128-ch
MAVH256_SP — 256-ch
MAVH256DP — 256-ch
MCM128 — 128-ch Omnetics
MCM64 — 64-ch Omnetics
MH128 — 128-ch Omnetics
MH32 — 32-ch
MH64 — 64-ch Omnetics
MHS128 — 128-ch Omnetics
MHS128_KN — 128-ch Omnetics
MHS128_P — 128-ch Omnetics
MHS64 — 64-ch Omnetics
MMH64 — 64-ch Omnetics
MMHS64 — 64-ch Omnetics
MX32 — 32-ch

Your selection

32-channel 4-shank silicon probe, 2 mm — 50 μm, MAVH256DP
MAVH256DP
Compatible Package: MAVH256DP — 256-ch
SKUprb_mtx--m4x8_poly3_2mm_25s_200_177.50um.mavh256dp
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

19 of 19
4-Shank 32-Channel Probe, 2 mmSKU prb_mtx--m4x8_poly3_2mm_25s_200_177

Loading the compatible products…

4-Shank 32-Channel Probe, 2 mmSKU prb_mtx--m4x8_poly3_2mm_25s_200_177

14 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
32
41024

Top 26% of catalog designs · largest in its family

Sites 32 — higher than 74% of catalog designs and 100% of its family (the largest in its family, 32 designs)
Shanks
4
116

Top 15% of catalog designs · largest in its family

Shanks 4 — higher than 85% of catalog designs and 100% of its family (the largest in its family, 32 designs)
Shank length
2 mm
1 mm60 mm

Top 92% of catalog designs

Shank length 2 mm — higher than 8% of catalog designs and 44% of its family
Shank separation
0.2 mm
0.05 mm1.8 mm

Top 68% of catalog designs

Shank separation 0.2 mm — higher than 32% of catalog designs and 31% of its family
Maximum site depth
1.9 mm
0.972 mm51.29 mm

Top 98% of catalog designs

Maximum site depth 1.9 mm — higher than 2% of catalog designs and 19% of its family
Minimum site depth
1.83 mm
0.067 mm44.74 mm

Top 89% of catalog designs

Minimum site depth 1.83 mm — higher than 11% of catalog designs and 59% of its family
Span, x
0.658 mm
0.01 mm6.03 mm

Top 30% of catalog designs

Span, x 0.658 mm — higher than 70% of catalog designs and 56% of its family
Span, y
0.065 mm
0.01 mm10.55 mm

Top 94% of catalog designs

Span, y 0.065 mm — higher than 6% of catalog designs and 9% of its family
Site pitch, x
0.022 µm
0.012 µm0.57 µm

Top 36% of catalog designs · largest in its family

Site pitch, x 0.022 µm — higher than 64% of catalog designs and 100% of its family (the largest in its family, 4 designs)
Site pitch, y
0.013 µm
0.01 µm1.5 µm

Top 94% of catalog designs

Site pitch, y 0.013 µm — higher than 6% of catalog designs and 9% of its family
Site outline area
0.043 mm²
0.002 mm²28.74 mm²

Top 73% of catalog designs

Site outline area 0.043 mm² — higher than 27% of catalog designs and 6% of its family
Neural interface volume
0.327 mm³
0.149 mm³17.19 mm³

Top 83% of catalog designs

Neural interface volume 0.327 mm³ — higher than 17% of catalog designs and 6% of its family
Site coverage density
749 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 21% of catalog designs · largest in its family

Site coverage density 749 sites/mm² — higher than 79% of catalog designs and 100% of its family (the largest in its family, 32 designs)
Brain coverage density
97.82 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 13% of catalog designs · largest in its family

Brain coverage density 97.82 sites/mm³ — higher than 87% of catalog designs and 100% of its family (the largest in its family, 32 designs)
4-Shank 32-Channel Probe, 2 mmSKU prb_mtx--m4x8_poly3_2mm_25s_200_177

6 notes · Three choices, made in order · Platform spacing sets the sampled volume · What it costs in the animal …

4-Shank 32-Channel Probe, 2 mmSKU prb_mtx--m4x8_poly3_2mm_25s_200_177

16 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

4-Shank 32-Channel Probe, 2 mmSKU prb_mtx--m4x8_poly3_2mm_25s_200_177

Cited in 2,342 publications (product line)
