32-site Matrix array, 4 shanks, 2 mm, 177 µm², 12.5 µm pitch, 400 µm apart
Four short shanks side by side, spread for lateral coverage across columns, with sites staggered in three columns so neighbouring sites see the same units. Among the 369 probe designs in the design space it is in the lower quartile: 32 sites (a common choice — 158 of 369), 2 mm shanks (8th percentile of the 366 measured), a 0.06 mm-deep site array (6th percentile), 392 sites/mm² (62nd percentile) and a 0.5 mm³ neural interface (31st percentile).
Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The short shanks suit superficial targets.
Orders as a probe-plus-package assembly, in 19 package configurations, 2 of them microdrive-compatible. Built for the Matrix Array platform: this 2D array installs in a Matrix package slot and is not assembled in other packages. Silicon 50 µm thick. Z-coat not available on this close-spaced poly layout. Research use only.
m4x8_poly3_2mm_25s__400_177
15 specs
| Platform | Matrix Array (one 2D array per platform slot) |
|---|---|
| Channels | 32 |
| Shanks | 4 |
| Shank length | 2 mm |
| Shank separation | 400 µm |
| Site layout | Poly3 |
| Site area | 177 µm² |
| Site pitch | 12.5 µm |
| Vertical span | 65 µm |
|---|---|
| Substrate | Silicon |
| Site material | Iridium |
| Thickness | 50 µm |
| Neural interface volume | 0.497 mm³ (higher than 31% of 369 designs) |
| Site coverage density | 391.8 sites/mm² (higher than 62% of 369 designs) |
| Brain coverage density | 64.4 sites/mm³ (higher than 70% of 369 designs) |
Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.
19 options
Configure
Your selection
32-channel 4-shank silicon probe, 2 mm — 50 μm, MAVH256DP
MAVH256DPOptions
19 of 19MAVH256DP — 256-ch
MH64 — 64-ch Omnetics
MHS128 — 128-ch Omnetics
MA128_W — 128-ch Omnetics
MA128_Y — 128-ch Omnetics
MA64 — 64-ch Omnetics
MCM128 — 128-ch Omnetics
MCM64 — 64-ch Omnetics
MH128 — 128-ch Omnetics
MH32 — 32-ch
MHS128_KN — 128-ch Omnetics
MHS128_P — 128-ch Omnetics
MHS64 — 64-ch Omnetics
MMH64 — 64-ch Omnetics
MMHS64 — 64-ch Omnetics
MAVH128_SP — 128-ch
MAVH128X2_SP_P — 128-ch
MAVH256_SP — 256-ch
MX32 — 32-ch
Loading the compatible products…
14 metrics
Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.
Top 26% of catalog designs · largest in its family
Sites 32 — higher than 74% of catalog designs and 100% of its family (the largest in its family, 32 designs)Top 15% of catalog designs · largest in its family
Shanks 4 — higher than 85% of catalog designs and 100% of its family (the largest in its family, 32 designs)Top 92% of catalog designs
Shank length 2 mm — higher than 8% of catalog designs and 44% of its familyTop 18% of catalog designs
Shank separation 0.4 mm — higher than 82% of catalog designs and 72% of its familyTop 98% of catalog designs
Maximum site depth 1.9 mm — higher than 2% of catalog designs and 19% of its familyTop 89% of catalog designs
Minimum site depth 1.83 mm — higher than 11% of catalog designs and 59% of its familyTop 16% of catalog designs
Span, x 1.26 mm — higher than 84% of catalog designs and 81% of its familyTop 94% of catalog designs
Span, y 0.065 mm — higher than 6% of catalog designs and 9% of its familyTop 36% of catalog designs · largest in its family
Site pitch, x 0.022 µm — higher than 64% of catalog designs and 100% of its family (the largest in its family, 4 designs)Top 94% of catalog designs
Site pitch, y 0.013 µm — higher than 6% of catalog designs and 9% of its familyTop 57% of catalog designs
Site outline area 0.082 mm² — higher than 43% of catalog designs and 13% of its familyTop 69% of catalog designs
Neural interface volume 0.497 mm³ — higher than 31% of catalog designs and 19% of its familyTop 38% of catalog designs
Site coverage density 391.8 sites/mm² — higher than 62% of catalog designs and 91% of its familyTop 30% of catalog designs
Brain coverage density 64.44 sites/mm³ — higher than 70% of catalog designs and 84% of its family6 notes · Three choices, made in order · Platform spacing sets the sampled volume · What it costs in the animal …
