Neural Probes · Matrix Array Series

Linear 4-Shank 28-Channel Probe, 2 mm

28Sites
4Shanks
2mmShank Length
200µmSite Pitch
Part no.M4x8-prox200-2mm-200-400-177
Contents

28-site Matrix array

Four short shanks side by side, spread for lateral coverage across columns, with sites spread evenly down each, one per row, for a profile across depth. Among the 369 probe designs in the design space it is mid-range: 28 sites (30th percentile), 2 mm shanks (8th percentile of the 366 measured), a 1.22 mm-deep site array (59th percentile), 19 sites/mm² (7th percentile) and a 1.47 mm³ neural interface (84th percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, spaced widely to span a structure rather than resolve within it. The short shanks suit superficial targets.

Orders as a probe-plus-package assembly, in 19 package configurations, 2 of them microdrive-compatible. Built for the Matrix Array platform: this 2D array installs in a Matrix package slot and is not assembled in other packages. Silicon 50 µm thick. Z-coat available. Research use only.

Also known as

m4x8_prox200_2mm_200_400_177

Linear 4-Shank 28-Channel Probe, 2 mmSKU prb_mtx--m4x8_prox200_2mm_200_400_177

14 specs

PlatformMatrix Array (one 2D array per platform slot)
Channels28
Shanks4
Shank length2 mm
Shank separation400 µm
Site area177 µm²
Site pitch200 µm
Vertical span1215 µm
SubstrateSilicon
Site materialIridium
Thickness50 µm
Neural interface volume1.471 mm³ (higher than 84% of 369 designs)
Site coverage density19.0 sites/mm² (higher than 7% of 369 designs)
Brain coverage density19.0 sites/mm³ (higher than 10% of 369 designs)
Linear 4-Shank 28-Channel Probe, 2 mmSKU prb_mtx--m4x8_prox200_2mm_200_400_177

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

19 options

Configure

Compatible Package
All
MA128_W — 128-ch Omnetics
MA128_Y — 128-ch Omnetics
MA64 — 64-ch Omnetics
MAVH128_SP — 128-ch
MAVH128X2_SP_P — 128-ch
MAVH256_SP — 256-ch
MAVH256DP — 256-ch
MCM128 — 128-ch Omnetics
MCM64 — 64-ch Omnetics
MH128 — 128-ch Omnetics
MH32 — 32-ch
MH64 — 64-ch Omnetics
MHS128 — 128-ch Omnetics
MHS128_KN — 128-ch Omnetics
MHS128_P — 128-ch Omnetics
MHS64 — 64-ch Omnetics
MMH64 — 64-ch Omnetics
MMHS64 — 64-ch Omnetics
MX32 — 32-ch

Your selection

28-channel 4-shank silicon probe, 2 mm — 50 μm, MA128_W
MA128_W
Compatible Package: MA128_W — 128-ch Omnetics
SKUprb_mtx--m4x8_prox200_2mm_200_400_177.50um.ma128_w
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

19 of 19
Linear 4-Shank 28-Channel Probe, 2 mmSKU prb_mtx--m4x8_prox200_2mm_200_400_177

Loading the compatible products…

Linear 4-Shank 28-Channel Probe, 2 mmSKU prb_mtx--m4x8_prox200_2mm_200_400_177

13 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
28
41024

Top 70% of catalog designs

Sites 28 — higher than 30% of catalog designs and 3% of its family
Shanks
4
116

Top 15% of catalog designs · largest in its family

Shanks 4 — higher than 85% of catalog designs and 100% of its family (the largest in its family, 32 designs)
Shank length
2 mm
1 mm60 mm

Top 92% of catalog designs

Shank length 2 mm — higher than 8% of catalog designs and 44% of its family
Shank separation
0.4 mm
0.05 mm1.8 mm

Top 11% of catalog designs

Shank separation 0.4 mm — higher than 89% of catalog designs and 79% of its family
Maximum site depth
1.61 mm
0.972 mm51.29 mm

Top 99% of catalog designs

Maximum site depth 1.61 mm — higher than 1% of catalog designs and 9% of its family
Minimum site depth
0.392 mm
0.067 mm44.74 mm

Top 99% of catalog designs

Minimum site depth 0.392 mm — higher than 1% of catalog designs and 16% of its family
Span, x
1.22 mm
0.01 mm6.03 mm

Top 20% of catalog designs

Span, x 1.22 mm — higher than 80% of catalog designs and 66% of its family
Span, y
1.22 mm
0.01 mm10.55 mm

Top 41% of catalog designs

Span, y 1.22 mm — higher than 59% of catalog designs and 66% of its family
Site pitch, y
0.2 µm
0.01 µm1.5 µm

Top 4% of catalog designs

Site pitch, y 0.2 µm — higher than 96% of catalog designs and 88% of its family
Site outline area
1.48 mm²
0.002 mm²28.74 mm²

Top 14% of catalog designs

Site outline area 1.48 mm² — higher than 86% of catalog designs and 69% of its family
Neural interface volume
1.47 mm³
0.149 mm³17.19 mm³

Top 16% of catalog designs

Neural interface volume 1.47 mm³ — higher than 84% of catalog designs and 66% of its family
Site coverage density
18.96 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 93% of catalog designs

Site coverage density 18.96 sites/mm² — higher than 7% of catalog designs and 34% of its family
Brain coverage density
19.04 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 90% of catalog designs

Brain coverage density 19.04 sites/mm³ — higher than 10% of catalog designs and 25% of its family
