Grids · Cardiac Surface Grid Series

Epicardial 64-Channel Array

64Sites
12µmThickness
28.57mmWidth
259,672µm²Site Area
Part no.Cs8x8-seg-4000-cl150-575
Contents

64-site cardiac surface grid, 28.6 × 28.6 mm

A thin polyimide film that lies on the epicardium and deforms with every beat, carrying large sites that average a broad patch at low impedance, on a long cable for routing to the connector. Among the 55 grid designs in the design space it sits at the top: 64 sites (a common choice — 9 of 55), a 29 mm site-array span (95th percentile), 0.08 sites/mm² (5th percentile) and a 423 mm³ neural interface (98th percentile).

Orders as a grid-plus-package assembly, in 5 package configurations, 3 of them microdrive-compatible. Polyimide 12 µm thick. 150 mm cable. Research use only.

Also known as

cs8x8_seg_4000_150_575

Epicardial 64-Channel ArraySKU grd_ecg--cs8x8_seg_4000_cl150_575

Estimated geometry — the site layout is not from a measured design file, so geometry-derived values are approximate.

11 specs

Channels64
Site layoutGrid
Site area259,672 µm²
Span28575 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Site geometryEstimated from the catalog drawing and similar designs
Neural interface volume422.678 mm³ (higher than 98% of 55 designs)
Site coverage density0.1 sites/mm² (higher than 5% of 55 designs)
Brain coverage density0.2 sites/mm³ (higher than 5% of 55 designs)
Epicardial 64-Channel ArraySKU grd_ecg--cs8x8_seg_4000_cl150_575

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

5 options

Configure

Compatible Package
All
H64 — 64-ch Omnetics
H64LP — 64-ch Omnetics
HC64 — 64-ch Omnetics
HZ64 — 64-ch Hirose
X3_H64 — 64-ch Molex

Your selection

64-channel thin-film epicardial array — H64, 12 μm
H64
Compatible Package: H64 — 64-ch Omnetics
SKUgrd_ecg--cs8x8_seg_4000_cl150_575.12um.h64
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.
