32-channel Hybrid package, optoelectrode, 21 mm cable
OH32LP carries 32 channels to an Omnetics 32-pin connector, over a 21 mm thin-film cable to a PCB carrying the connector, in UV epoxy.
A Hybrid package (H-style package) mounts a silicon probe to one end of a thin-film polyimide ribbon cable, with the other end of the cable attached to a PCB and connector, so the probe is mechanically uncoupled from the connector; the thin-film cable is very flexible and can even twist slightly. The "H" stands for hybrid assembly, the hybrid of a thin-film silicon probe and a thin-film polymer component, silicon and polymer.
For chronic implants: the probe is mechanically uncoupled from the head-fixed connector and moves with the tissue. Optical stimulation runs from a separate laser or LED source. Cable length 21 mm. Mates with an Omnetics 32-pin on the headstage side. Available as a fully assembled probe assembly.
OH32LP
5 specs
| Channels | 32 |
|---|---|
| Connector | Omnetics 32-pin |
| Construction | Cabled: thin-film cable to the connector PCB |
| Cable length | 21 mm |
| Protective covering | UV epoxy |
