Grids · Nerve-Cuff Series

Nerve-Cuff 24-Channel Array

24Sites
12µmThickness
6.66mmWidth
171,600µm²Site Area
Part no.C24-3000-cl50mm
Contents

24-site nerve cuff grid, 467 µm sites

A thin polyimide film pre-curved to wrap a peripheral nerve from the outside, carrying large sites that average a broad patch at low impedance. Among the 55 grid designs in the design space it is mid-range: 24 sites (31st percentile), a 2.73 mm site-array span (29th percentile), 1.32 sites/mm² (53rd percentile) and a 12 mm³ neural interface (44th percentile).

Orders as a grid-plus-package assembly, in 7 package configurations, 3 of them microdrive-compatible. Polyimide 12 µm thick. Research use only.

Also known as

c24_3000 · c24_50mm

Nerve-Cuff 24-Channel ArraySKU grd_ncf--c24_3000_cl50mm

10 specs

Channels24
Site layoutGrid
Site area171,600 µm²
Span2731 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Neural interface volume11.567 mm³ (higher than 44% of 55 designs)
Site coverage density1.3 sites/mm² (higher than 53% of 55 designs)
Brain coverage density2.1 sites/mm³ (higher than 51% of 55 designs)
Nerve-Cuff 24-Channel ArraySKU grd_ncf--c24_3000_cl50mm

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

7 options

Configure

Compatible Package
All
H32 — 32-ch Omnetics
HC32 — 32-ch Omnetics
HZ32 — 32-ch Hirose
HZ32 (21 mm cable) — 32-ch Hirose
MRH32 — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
X3_H32 — 32-ch Molex

Your selection

24-channel thin-film nerve-cuff array — HZ32, 12 μm
HZ32
Compatible Package: HZ32 — 32-ch Hirose
SKUgrd_ncf--c24_3000_cl50mm.12um.hz32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

7 of 7
Nerve-Cuff 24-Channel ArraySKU grd_ncf--c24_3000_cl50mm

Loading the compatible products…

Nerve-Cuff 24-Channel ArraySKU grd_ncf--c24_3000_cl50mm

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
24
3256

Top 69% of catalog designs · largest in its family

Sites 24 — higher than 31% of catalog designs and 100% of its family (the largest in its family, 6 designs)
Span, x
6.66 mm
0.1 mm36.5 mm

Top 47% of catalog designs

Span, x 6.66 mm — higher than 53% of catalog designs and 50% of its family
Span, y
2.73 mm
0.26 mm79 mm

Top 71% of catalog designs

Span, y 2.73 mm — higher than 29% of catalog designs and 33% of its family
Site pitch, x
3 µm
0.15 µm6 µm

Top 9% of catalog designs · largest in its family

Site pitch, x 3 µm — higher than 91% of catalog designs and 100% of its family (the largest in its family, 5 designs)
Site pitch, y
0.353 µm
0.08 µm5.59 µm

Top 80% of catalog designs

Site pitch, y 0.353 µm — higher than 20% of catalog designs and 33% of its family
Site outline area
18.19 mm²
0.026 mm²970.7 mm²

Top 56% of catalog designs

Site outline area 18.19 mm² — higher than 44% of catalog designs and 50% of its family
Neural interface volume
11.57 mm³
0.228 mm³501.1 mm³

Top 56% of catalog designs

Neural interface volume 11.57 mm³ — higher than 44% of catalog designs and 50% of its family
Site coverage density
1.32 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 47% of catalog designs

Site coverage density 1.32 sites/mm² — higher than 53% of catalog designs and 67% of its family
Brain coverage density
2.07 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 49% of catalog designs

Brain coverage density 2.07 sites/mm³ — higher than 51% of catalog designs and 67% of its family
Nerve-Cuff 24-Channel ArraySKU grd_ncf--c24_3000_cl50mm

5 notes · Diameter is chosen, not adjusted · The sieve variant · Coverage and site layout …

Nerve-Cuff 24-Channel ArraySKU grd_ncf--c24_3000_cl50mm

14 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

Nerve-Cuff 24-Channel ArraySKU grd_ncf--c24_3000_cl50mm

Cited in 74 publications (product line)
