Buzsaki 4-Shank 32-Channel Probe, 10 mm
32-channel 4-shank silicon probe, 10 mm
32-channel silicon probe — 4 shanks carrying Buzsaki-layout sites (165 µm², 20 µm pitch) on 10 mm shanks. Closely spaced sites staggered near the tip of each shank, so one neuron appears on several sites and units separate in sorting.
buzsaki32spl
14 specs
| Channels | 32 |
|---|---|
| Shanks | 4 |
| Shank length | 10 mm |
| Shank separation | 200 µm |
| Site layout | Buzsaki |
| Site area | 165 µm² |
| Site pitch | 20 µm |
| Vertical span | 155 µm |
|---|---|
| Substrate | Silicon |
| Site material | Iridium |
| Thickness | 15, 50 µm |
| Neural interface volume | 0.376 mm³ (higher than 23% of 369 designs) |
| Site coverage density | 318.6 sites/mm² (higher than 57% of 369 designs) |
| Brain coverage density | 85.1 sites/mm³ (higher than 80% of 369 designs) |
Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.
54 options
Configure
Your selection
32-channel 4-shank silicon probe, 10 mm — 15 μm, A32
A32Options
54 of 5415 μm · A32 — 32-ch Samtec
50 μm · A32 — 32-ch Samtec
15 μm · CM32 — 32-ch Omnetics
50 μm · CM32 — 32-ch Omnetics
15 μm · H32 — 32-ch Omnetics
50 μm · H32 — 32-ch Omnetics
15 μm · H32 (200 mm cable) — 32-ch Omnetics
50 μm · H32 (200 mm cable) — 32-ch Omnetics
15 μm · H32 (21 mm cable) — 32-ch Omnetics
50 μm · H32 (21 mm cable) — 32-ch Omnetics
15 μm · H32 (50 mm cable) — 32-ch Omnetics
50 μm · H32 (50 mm cable) — 32-ch Omnetics
15 μm · HC32 — 32-ch Omnetics
50 μm · HC32 — 32-ch Omnetics
15 μm · MRCM16PB32 — 16-ch
50 μm · MRCM16PB32 — 16-ch
15 μm · MRCM32 — 32-ch
50 μm · MRCM32 — 32-ch
15 μm · MROCM32LP — 32-ch Omnetics
50 μm · MROCM32LP — 32-ch Omnetics
15 μm · OA32LP — 32-ch Samtec
50 μm · OA32LP — 32-ch Samtec
15 μm · OA32LP_V2 — 32-ch Samtec
50 μm · OA32LP_V2 — 32-ch Samtec
15 μm · OCM32LP — 32-ch Omnetics
50 μm · OCM32LP — 32-ch Omnetics
15 μm · OHZ32LP — 32-ch Hirose
50 μm · OHZ32LP — 32-ch Hirose
15 μm · OXA32LP — 32-ch Samtec
50 μm · OXA32LP — 32-ch Samtec
15 μm · OXCM32LP — 32-ch Omnetics
50 μm · OXCM32LP — 32-ch Omnetics
15 μm · OZ32LP — 32-ch Hirose
50 μm · OZ32LP — 32-ch Hirose
15 μm · X3_32 — 32-ch Molex
50 μm · X3_32 — 32-ch Molex
15 μm · Z32 — 32-ch Hirose
50 μm · Z32 — 32-ch Hirose
15 μm · HZ32 — 32-ch Hirose
50 μm · HZ32 — 32-ch Hirose
15 μm · MRH32 — 32-ch Omnetics
50 μm · MRH32 — 32-ch Omnetics
15 μm · MRHC32 — 32-ch Omnetics
50 μm · MRHC32 — 32-ch Omnetics
15 μm · OH32LP — 32-ch Omnetics
50 μm · OH32LP — 32-ch Omnetics
15 μm · F64 — 64-ch Omnetics
50 μm · F64 — 64-ch Omnetics
15 μm · FH64 — 64-ch Omnetics
50 μm · FH64 — 64-ch Omnetics
15 μm · OXH32LP_21MM — 32-ch
50 μm · OXH32LP_21MM — 32-ch
15 μm · X3_H32 — 32-ch Molex
50 μm · X3_H32 — 32-ch Molex
Loading the compatible products…
13 metrics
Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.
Top 26% of catalog designs
Sites 32 — higher than 74% of catalog designs and 40% of its familyTop 15% of catalog designs
Shanks 4 — higher than 85% of catalog designs and 47% of its familyTop 10% of catalog designs
Shank length 10 mm — higher than 90% of catalog designs and 87% of its familyTop 35% of catalog designs
Shank separation 0.2 mm — higher than 65% of catalog designs and 92% of its familyTop 11% of catalog designs
Maximum site depth 9.99 mm — higher than 89% of catalog designs and 80% of its familyTop 8% of catalog designs
Minimum site depth 9.83 mm — higher than 92% of catalog designs and 87% of its familyTop 31% of catalog designs
Span, x 0.648 mm — higher than 69% of catalog designs and 47% of its familyTop 92% of catalog designs
Span, y 0.155 mm — higher than 8% of catalog designs and 33% of its familyTop 78% of catalog designs
Site pitch, y 0.02 µm — higher than 22% of catalog designs and 73% of its familyTop 54% of catalog designs
Site outline area 0.1 mm² — higher than 46% of catalog designs and 27% of its familyTop 77% of catalog designs
Neural interface volume 0.376 mm³ — higher than 23% of catalog designs and 27% of its familyTop 43% of catalog designs
Site coverage density 318.6 sites/mm² — higher than 57% of catalog designs and 87% of its familyTop 20% of catalog designs
Brain coverage density 85.11 sites/mm³ — higher than 80% of catalog designs and 80% of its family4 notes · Why the sites sit at the tip · Geometry · Construction …
15 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …
Cited in 2,342 publications (product line)
