Neural Probes · A-Series (Buzsaki)

Buzsaki 4-Shank 32-Channel Probe, 10 mm

32Sites
4Shanks
10mmShank Length
20µmSite Pitch
Part no.Buz32l-10mm
Contents

32-channel 4-shank silicon probe, 10 mm

32-channel silicon probe — 4 shanks carrying Buzsaki-layout sites (165 µm², 20 µm pitch) on 10 mm shanks. Closely spaced sites staggered near the tip of each shank, so one neuron appears on several sites and units separate in sorting.

Also known as

buzsaki32l

Buzsaki 4-Shank 32-Channel Probe, 10 mmSKU prb_abz--buz32l_10mm

14 specs

Channels32
Shanks4
Shank length10 mm
Shank separation200 µm
Site layoutBuzsaki
Site area165 µm²
Site pitch20 µm
Vertical span155 µm
SubstrateSilicon
Site materialIridium
Thickness15, 50 µm
Neural interface volume0.376 mm³ (higher than 23% of 369 designs)
Site coverage density318.6 sites/mm² (higher than 57% of 369 designs)
Brain coverage density85.1 sites/mm³ (higher than 80% of 369 designs)
Buzsaki 4-Shank 32-Channel Probe, 10 mmSKU prb_abz--buz32l_10mm

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

48 options

Configure

Substrate Thickness
All
15 μm
50 μm
Compatible Package
All
A32 — 32-ch Samtec
CM32 — 32-ch Omnetics
F64 — 64-ch Omnetics
FH64 — 64-ch Omnetics
H32 (21 mm cable) — 32-ch Omnetics
HC32 (21 mm cable) — 32-ch Omnetics
HZ32 (21 mm cable) — 32-ch Hirose
MRCM16PB32 — 16-ch
MRCM32 — 32-ch
MRH32 (21 mm cable) — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
MROCM32LP — 32-ch Omnetics
OA32LP — 32-ch Samtec
OA32LP_V2 — 32-ch Samtec
OCM32LP — 32-ch Omnetics
OH32LP (21 mm cable) — 32-ch Omnetics
OHZ32LP — 32-ch Hirose
OXA32LP — 32-ch Samtec
OXCM32LP — 32-ch Omnetics
OXH32LP_21MM — 32-ch
OZ32LP — 32-ch Hirose
X3_32 — 32-ch Molex
X3_H32 (21 mm cable) — 32-ch Molex
Z32 — 32-ch Hirose

Your selection

32-channel 4-shank silicon probe, 10 mm — 15 μm, A32
A32
Substrate Thickness: 15 μm
Compatible Package: A32 — 32-ch Samtec
SKUprb_abz--buz32l_10mm.15um.a32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

48 of 48
Buzsaki 4-Shank 32-Channel Probe, 10 mmSKU prb_abz--buz32l_10mm

Loading the compatible products…

Buzsaki 4-Shank 32-Channel Probe, 10 mmSKU prb_abz--buz32l_10mm

13 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
32
41024

Top 26% of catalog designs

Sites 32 — higher than 74% of catalog designs and 40% of its family
Shanks
4
116

Top 15% of catalog designs

Shanks 4 — higher than 85% of catalog designs and 47% of its family
Shank length
10 mm
1 mm60 mm

Top 10% of catalog designs

Shank length 10 mm — higher than 90% of catalog designs and 87% of its family
Shank separation
0.2 mm
0.05 mm1.8 mm

Top 35% of catalog designs

Shank separation 0.2 mm — higher than 65% of catalog designs and 92% of its family
Maximum site depth
9.99 mm
0.972 mm51.29 mm

Top 11% of catalog designs

Maximum site depth 9.99 mm — higher than 89% of catalog designs and 80% of its family
Minimum site depth
9.83 mm
0.067 mm44.74 mm

Top 8% of catalog designs

Minimum site depth 9.83 mm — higher than 92% of catalog designs and 87% of its family
Span, x
0.648 mm
0.01 mm6.03 mm

Top 31% of catalog designs

Span, x 0.648 mm — higher than 69% of catalog designs and 47% of its family
Span, y
0.155 mm
0.01 mm10.55 mm

Top 92% of catalog designs

Span, y 0.155 mm — higher than 8% of catalog designs and 33% of its family
Site pitch, y
0.02 µm
0.01 µm1.5 µm

Top 78% of catalog designs

Site pitch, y 0.02 µm — higher than 22% of catalog designs and 73% of its family
Site outline area
0.1 mm²
0.002 mm²28.74 mm²

Top 54% of catalog designs

Site outline area 0.1 mm² — higher than 46% of catalog designs and 27% of its family
Neural interface volume
0.376 mm³
0.149 mm³17.19 mm³

Top 77% of catalog designs

Neural interface volume 0.376 mm³ — higher than 23% of catalog designs and 27% of its family
Site coverage density
318.6 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 43% of catalog designs

Site coverage density 318.6 sites/mm² — higher than 57% of catalog designs and 87% of its family
Brain coverage density
85.11 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 20% of catalog designs

Brain coverage density 85.11 sites/mm³ — higher than 80% of catalog designs and 80% of its family
