Neural Probes · A-Series (Buzsaki)

Buzsaki 6-Shank 64-Channel Probe, 15 mm

64Sites
6Shanks
15mmShank Length
20µmSite Pitch
Part no.Buz64-SP-15mm
Contents

64-site Buzsaki probe, 6 shanks, 15 mm

Six long shanks side by side, closely spaced for coverage within one structure, with sites staggered near the edges of each tip — the Buzsaki layout for spike discrimination. Among the 369 probe designs in the design space it is in the upper quartile: 64 sites (a common choice — 65 of 369), 15 mm shanks (98th percentile of the 366 measured), a 2 mm-deep site array (81st percentile), 31 sites/mm² (11th percentile) and a 1.92 mm³ neural interface (90th percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The long shanks reach deep targets.

Orders as a probe-plus-package assembly, in 23 package configurations, 5 of them microdrive-compatible. Silicon 15 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.

Also known as

buzsaki64_sp_15mm

Buzsaki 6-Shank 64-Channel Probe, 15 mmSKU prb_abz--buz64_sp_15mm

14 specs

Channels64
Shanks6
Shank length15 mm
Shank separation200 µm
Site layoutBuzsaki
Site area165 µm²
Site pitch20 µm
Vertical span1995 µm
SubstrateSilicon
Site materialIridium
Thickness15 µm
Neural interface volume1.925 mm³ (higher than 90% of 369 designs)
Site coverage density30.8 sites/mm² (higher than 11% of 369 designs)
Brain coverage density33.2 sites/mm³ (higher than 33% of 369 designs)
Buzsaki 6-Shank 64-Channel Probe, 15 mmSKU prb_abz--buz64_sp_15mm

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

23 options

Configure

Compatible Package
All
A64 — 64-ch Samtec
AV64 — 64-ch
AVH64 — 64-ch
AVI64 — 64-ch Omnetics
AVIH64 — 64-ch Omnetics
EIB64 — 64-ch Molex
F128 — 128-ch Omnetics
FH128 — 128-ch Omnetics
H64 (30 mm cable) — 64-ch Omnetics
H64_60MM — 64-ch
H64LP — 64-ch Omnetics
HC64 — 64-ch Omnetics
HZ64 — 64-ch Hirose
MRH64LP_30MM — 64-ch
MRHC64 — 64-ch Omnetics
OA64LP — 64-ch Samtec
OA64LP_V2 — 64-ch Samtec
OH64LP — 64-ch Omnetics
OXA64LP — 64-ch Samtec
SEACM64 — 64-ch Samtec
X3_64 — 64-ch Molex
X3_H64 — 64-ch Molex
Z64 — 64-ch Hirose

Your selection

64-channel 6-shank silicon probe, 15 mm — 15 μm, A64
A64
Compatible Package: A64 — 64-ch Samtec
SKUprb_abz--buz64_sp_15mm.15um.a64
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

23 of 23
Buzsaki 6-Shank 64-Channel Probe, 15 mmSKU prb_abz--buz64_sp_15mm

Loading the compatible products…

Buzsaki 6-Shank 64-Channel Probe, 15 mmSKU prb_abz--buz64_sp_15mm

13 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
64
41024

Top 8% of catalog designs

Sites 64 — higher than 92% of catalog designs and 93% of its family
Shanks
6
116

Top 13% of catalog designs

Shanks 6 — higher than 87% of catalog designs and 80% of its family
Shank length
15 mm
1 mm60 mm

Top 2% of catalog designs · largest in its family

Shank length 15 mm — higher than 98% of catalog designs and 100% of its family (the largest in its family, 15 designs)
Shank separation
0.2 mm
0.05 mm1.8 mm

Top 35% of catalog designs

Shank separation 0.2 mm — higher than 65% of catalog designs and 92% of its family
Maximum site depth
14.99 mm
0.972 mm51.29 mm

Top 2% of catalog designs · largest in its family

Maximum site depth 14.99 mm — higher than 98% of catalog designs and 100% of its family (the largest in its family, 15 designs)
Minimum site depth
12.99 mm
0.067 mm44.74 mm

Top 4% of catalog designs · largest in its family

Minimum site depth 12.99 mm — higher than 96% of catalog designs and 100% of its family (the largest in its family, 15 designs)
Span, x
1.04 mm
0.01 mm6.03 mm

Top 24% of catalog designs

Span, x 1.04 mm — higher than 76% of catalog designs and 67% of its family
Span, y
2 mm
0.01 mm10.55 mm

Top 19% of catalog designs

Span, y 2 mm — higher than 81% of catalog designs and 87% of its family
Site pitch, y
0.02 µm
0.01 µm1.5 µm

Top 78% of catalog designs

Site pitch, y 0.02 µm — higher than 22% of catalog designs and 73% of its family
Site outline area
2.08 mm²
0.002 mm²28.74 mm²

Top 9% of catalog designs

Site outline area 2.08 mm² — higher than 91% of catalog designs and 67% of its family
Neural interface volume
1.92 mm³
0.149 mm³17.19 mm³

Top 10% of catalog designs

Neural interface volume 1.92 mm³ — higher than 90% of catalog designs and 67% of its family
Site coverage density
30.76 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 89% of catalog designs

Site coverage density 30.76 sites/mm² — higher than 11% of catalog designs and 33% of its family
Brain coverage density
33.25 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 67% of catalog designs

Brain coverage density 33.25 sites/mm³ — higher than 33% of catalog designs and 33% of its family
