Neural Probes · A-Series (Buzsaki)

Buzsaki 6-Shank 64-Channel Probe, 10 mm

64Sites
6Shanks
10mmShank Length
20µmSite Pitch
Part no.Buz64-Spl-10mm
Contents

64-site Buzsaki probe, 6 shanks, 10 mm

Six long shanks side by side, closely spaced for coverage within one structure, with sites staggered near the edges of each tip — the Buzsaki layout for spike discrimination. Among the 369 probe designs in the design space it is in the upper quartile: 64 sites (a common choice — 65 of 369), 10 mm shanks (a common choice — 80 of 366), a 2 mm-deep site array (81st percentile), 31 sites/mm² (10th percentile) and a 1.92 mm³ neural interface (91st percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The long shanks reach deep targets.

Orders as a probe-plus-package assembly, in 22 package configurations, 2 of them microdrive-compatible. Silicon 15 or 50 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.

Also known as

buzsaki64spl

Buzsaki 6-Shank 64-Channel Probe, 10 mmSKU prb_abz--buz64_spl_10mm

14 specs

Channels64
Shanks6
Shank length10 mm
Shank separation200 µm
Site layoutBuzsaki
Site area165 µm²
Site pitch20 µm
Vertical span1995 µm
SubstrateSilicon
Site materialIridium
Thickness15, 50 µm
Neural interface volume1.925 mm³ (higher than 91% of 369 designs)
Site coverage density30.8 sites/mm² (higher than 10% of 369 designs)
Brain coverage density33.2 sites/mm³ (higher than 33% of 369 designs)
Buzsaki 6-Shank 64-Channel Probe, 10 mmSKU prb_abz--buz64_spl_10mm

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

44 options

Configure

Substrate Thickness
All
15 μm
50 μm
Compatible Package
All
A64 — 64-ch Samtec
AV64 — 64-ch
AVH64 — 64-ch
AVI64 — 64-ch Omnetics
AVIH64 — 64-ch Omnetics
EIB64 — 64-ch Molex
F128 — 128-ch Omnetics
FH128 — 128-ch Omnetics
H64 (30 mm cable) — 64-ch Omnetics
H64LP (30 mm cable) — 64-ch Omnetics
HC64 (30 mm cable) — 64-ch Omnetics
HZ64 (30 mm cable) — 64-ch Hirose
MRH64LP_30MM — 64-ch
MRHC64 — 64-ch Omnetics
OA64LP — 64-ch Samtec
OA64LP_V2 — 64-ch Samtec
OH64LP — 64-ch Omnetics
OXA64LP — 64-ch Samtec
SEACM64 — 64-ch Samtec
X3_64 — 64-ch Molex
X3_H64 (30 mm cable) — 64-ch Molex
Z64 — 64-ch Hirose

Your selection

64-channel 6-shank silicon probe, 10 mm — 15 μm, A64
A64
Substrate Thickness: 15 μm
Compatible Package: A64 — 64-ch Samtec
SKUprb_abz--buz64_spl_10mm.15um.a64
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

44 of 44
Buzsaki 6-Shank 64-Channel Probe, 10 mmSKU prb_abz--buz64_spl_10mm

Loading the compatible products…

Buzsaki 6-Shank 64-Channel Probe, 10 mmSKU prb_abz--buz64_spl_10mm

13 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
64
41024

Top 8% of catalog designs

Sites 64 — higher than 92% of catalog designs and 93% of its family
Shanks
6
116

Top 13% of catalog designs

Shanks 6 — higher than 87% of catalog designs and 80% of its family
Shank length
10 mm
1 mm60 mm

Top 10% of catalog designs

Shank length 10 mm — higher than 90% of catalog designs and 87% of its family
Shank separation
0.2 mm
0.05 mm1.8 mm

Top 35% of catalog designs

Shank separation 0.2 mm — higher than 65% of catalog designs and 92% of its family
Maximum site depth
9.99 mm
0.972 mm51.29 mm

Top 11% of catalog designs

Maximum site depth 9.99 mm — higher than 89% of catalog designs and 87% of its family
Minimum site depth
7.99 mm
0.067 mm44.74 mm

Top 25% of catalog designs

Minimum site depth 7.99 mm — higher than 75% of catalog designs and 67% of its family
Span, x
1.04 mm
0.01 mm6.03 mm

Top 23% of catalog designs

Span, x 1.04 mm — higher than 77% of catalog designs and 80% of its family
Span, y
2 mm
0.01 mm10.55 mm

Top 19% of catalog designs

Span, y 2 mm — higher than 81% of catalog designs and 87% of its family
Site pitch, y
0.02 µm
0.01 µm1.5 µm

Top 78% of catalog designs

Site pitch, y 0.02 µm — higher than 22% of catalog designs and 73% of its family
Site outline area
2.08 mm²
0.002 mm²28.74 mm²

Top 9% of catalog designs

Site outline area 2.08 mm² — higher than 91% of catalog designs and 80% of its family
Neural interface volume
1.92 mm³
0.149 mm³17.19 mm³

Top 9% of catalog designs

Neural interface volume 1.92 mm³ — higher than 91% of catalog designs and 80% of its family
Site coverage density
30.76 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 90% of catalog designs

Site coverage density 30.76 sites/mm² — higher than 10% of catalog designs and 27% of its family
Brain coverage density
33.25 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 67% of catalog designs

Brain coverage density 33.25 sites/mm³ — higher than 33% of catalog designs and 27% of its family
