Neural Probes · A-Series (Polytrode & Tetrode)

Single-Shank 32-Channel Probe, 6 mm

32Sites
1Shanks
6mmShank Length
17.5µmSite Pitch
Part no.A1x32-Poly5-6mm-35s-100
Contents

32-site A-Series polytrode/tetrode probe, 1 shank, 6 mm, 98 µm²

A single mid-length shank with sites staggered in five columns so neighbouring sites see the same units. Among the 369 probe designs in the design space it is mid-range: 32 sites (a common choice — 158 of 369), 6 mm shanks (61st percentile of the 366 measured), a 0.24 mm-deep site array (14th percentile), 1,408 sites/mm² (91st percentile) and a 0.22 mm³ neural interface (5th percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The mid-length shank reaches structures a few millimetres down.

Orders as a probe-plus-package assembly, in 24 package configurations, 3 of them microdrive-compatible. Silicon 15 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.

Also known as

a1x32_poly5_6mm_35s_100

Single-Shank 32-Channel Probe, 6 mmSKU prb_ahc--a1x32_poly5_6mm_35s_100

13 specs

Channels32
Shanks1
Shank length6 mm
Site layoutPoly5
Site area98 µm²
Site pitch17.5 µm
Vertical span239 µm
SubstrateSilicon
Site materialIridium
Thickness15 µm
Neural interface volume0.220 mm³ (higher than 5% of 369 designs)
Site coverage density1,408.1 sites/mm² (higher than 91% of 369 designs)
Brain coverage density145.6 sites/mm³ (higher than 94% of 369 designs)
Single-Shank 32-Channel Probe, 6 mmSKU prb_ahc--a1x32_poly5_6mm_35s_100

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

24 options

Configure

Compatible Package
All
A32 — 32-ch Samtec
CM32 — 32-ch Omnetics
F64 — 64-ch Omnetics
FH64 — 64-ch Omnetics
H32 (21 mm cable) — 32-ch Omnetics
HC32 — 32-ch Omnetics
HZ32 — 32-ch Hirose
MRCM16PB32 — 16-ch
MRCM32 — 32-ch
MRH32 — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
MROCM32LP — 32-ch Omnetics
OA32LP — 32-ch Samtec
OA32LP_V2 — 32-ch Samtec
OCM32LP — 32-ch Omnetics
OH32LP — 32-ch Omnetics
OHZ32LP — 32-ch Hirose
OXA32LP — 32-ch Samtec
OXCM32LP — 32-ch Omnetics
OXH32LP_21MM — 32-ch
OZ32LP — 32-ch Hirose
X3_32 — 32-ch Molex
X3_H32 (21 mm cable) — 32-ch Molex
Z32 — 32-ch Hirose

Your selection

32-channel single-shank silicon probe, 6 mm — 15 μm, A32
A32
Compatible Package: A32 — 32-ch Samtec
SKUprb_ahc--a1x32_poly5_6mm_35s_100.15um.a32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

24 of 24
Single-Shank 32-Channel Probe, 6 mmSKU prb_ahc--a1x32_poly5_6mm_35s_100

Loading the compatible products…

Single-Shank 32-Channel Probe, 6 mmSKU prb_ahc--a1x32_poly5_6mm_35s_100

13 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
32
41024

Top 26% of catalog designs

Sites 32 — higher than 74% of catalog designs and 56% of its family
Shanks
1
116

Top 58% of catalog designs

Shanks 1 — higher than 42% of catalog designs and 35% of its family
Shank length
6 mm
1 mm60 mm

Top 39% of catalog designs

Shank length 6 mm — higher than 61% of catalog designs and 65% of its family
Maximum site depth
5.97 mm
0.972 mm51.29 mm

Top 40% of catalog designs

Maximum site depth 5.97 mm — higher than 60% of catalog designs and 61% of its family
Minimum site depth
5.73 mm
0.067 mm44.74 mm

Top 35% of catalog designs

Minimum site depth 5.73 mm — higher than 65% of catalog designs and 67% of its family
Span, x
0.095 mm
0.01 mm6.03 mm

Top 62% of catalog designs

Span, x 0.095 mm — higher than 38% of catalog designs and 23% of its family
Span, y
0.239 mm
0.01 mm10.55 mm

Top 86% of catalog designs

Span, y 0.239 mm — higher than 14% of catalog designs and 23% of its family
Site pitch, x
0.014 µm
0.012 µm0.57 µm

Top 90% of catalog designs

Site pitch, x 0.014 µm — higher than 10% of catalog designs and 4% of its family
Site pitch, y
0.018 µm
0.01 µm1.5 µm

Top 93% of catalog designs

Site pitch, y 0.018 µm — higher than 7% of catalog designs and 24% of its family
Site outline area
0.023 mm²
0.002 mm²28.74 mm²

Top 84% of catalog designs

Site outline area 0.023 mm² — higher than 16% of catalog designs and 8% of its family
Neural interface volume
0.22 mm³
0.149 mm³17.19 mm³

Top 95% of catalog designs

Neural interface volume 0.22 mm³ — higher than 5% of catalog designs and 3% of its family
Site coverage density
1408.1 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 9% of catalog designs

Site coverage density 1408.1 sites/mm² — higher than 91% of catalog designs and 97% of its family
Brain coverage density
145.6 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 6% of catalog designs

Brain coverage density 145.6 sites/mm³ — higher than 94% of catalog designs and 81% of its family
Single-Shank 32-Channel Probe, 6 mmSKU prb_ahc--a1x32_poly5_6mm_35s_100

5 notes · Polytrode and tetrode are two ways to cluster · Site area is the isolation variable · Geometry …

Single-Shank 32-Channel Probe, 6 mmSKU prb_ahc--a1x32_poly5_6mm_35s_100

17 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

Single-Shank 32-Channel Probe, 6 mmSKU prb_ahc--a1x32_poly5_6mm_35s_100

Cited in 2,342 publications (product line)
