Neural Probes · A-Series (Polytrode & Tetrode)

Tetrode 4-Shank 32-Channel Probe, 5 mm

32Sites
4Shanks
5mmShank Length
17.68µmSite Pitch
Part no.A4x2-tet-5mm-150-200-121
Contents

32-site A-Series polytrode/tetrode probe, 4 shanks, 17.68 µm pitch

Four mid-length shanks side by side, closely spaced for coverage within one structure, with sites grouped in tetrodes at intervals, for unit isolation at set depths. Among the 369 probe designs in the design space it is in the lower quartile: 32 sites (a common choice — 158 of 369), 5 mm shanks (a common choice — 108 of 366), a 0.2 mm-deep site array (12th percentile), 252 sites/mm² (52nd percentile) and a 0.4 mm³ neural interface (24th percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The mid-length shanks reach structures a few millimetres down.

Orders as a probe-plus-package assembly, in 24 package configurations, 2 of them microdrive-compatible. Silicon 15 or 50 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.

Also known as

a4x2_tet_5mm_150_200_121 · a4x2_tet_5mm_150_200_121_hz

Tetrode 4-Shank 32-Channel Probe, 5 mmSKU prb_ahc--a4x2_tet_5mm_150_200_121

14 specs

Channels32
Shanks4
Shank length5 mm
Shank separation200 µm
Site layoutTetrode
Site area121 µm²
Site pitch17.68 µm
Vertical span196 µm
SubstrateSilicon
Site materialIridium
Thickness15, 50 µm
Neural interface volume0.399 mm³ (higher than 24% of 369 designs)
Site coverage density252.1 sites/mm² (higher than 52% of 369 designs)
Brain coverage density80.2 sites/mm³ (higher than 79% of 369 designs)
Tetrode 4-Shank 32-Channel Probe, 5 mmSKU prb_ahc--a4x2_tet_5mm_150_200_121

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

48 options

Configure

Substrate Thickness
All
15 μm
50 μm
Compatible Package
All
A32 — 32-ch Samtec
CM32 — 32-ch Omnetics
F64 — 64-ch Omnetics
FH64 — 64-ch Omnetics
H32 (21 mm cable) — 32-ch Omnetics
HC32 (21 mm cable) — 32-ch Omnetics
HZ32 — 32-ch Hirose
MRCM16PB32 — 16-ch
MRCM32 — 32-ch
MRH32 (21 mm cable) — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
MROCM32LP — 32-ch Omnetics
OA32LP — 32-ch Samtec
OA32LP_V2 — 32-ch Samtec
OCM32LP — 32-ch Omnetics
OH32LP (21 mm cable) — 32-ch Omnetics
OHZ32LP — 32-ch Hirose
OXA32LP — 32-ch Samtec
OXCM32LP — 32-ch Omnetics
OXH32LP_21MM — 32-ch
OZ32LP — 32-ch Hirose
X3_32 — 32-ch Molex
X3_H32 (21 mm cable) — 32-ch Molex
Z32 — 32-ch Hirose

Your selection

32-channel 4-shank silicon probe, 5 mm — 15 μm, A32
A32
Substrate Thickness: 15 μm
Compatible Package: A32 — 32-ch Samtec
SKUprb_ahc--a4x2_tet_5mm_150_200_121.15um.a32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

48 of 48
Tetrode 4-Shank 32-Channel Probe, 5 mmSKU prb_ahc--a4x2_tet_5mm_150_200_121

Loading the compatible products…

Tetrode 4-Shank 32-Channel Probe, 5 mmSKU prb_ahc--a4x2_tet_5mm_150_200_121

14 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
32
41024

Top 26% of catalog designs

Sites 32 — higher than 74% of catalog designs and 56% of its family
Shanks
4
116

Top 15% of catalog designs

Shanks 4 — higher than 85% of catalog designs and 84% of its family
Shank length
5 mm
1 mm60 mm

Top 48% of catalog designs

Shank length 5 mm — higher than 52% of catalog designs and 51% of its family
Shank separation
0.2 mm
0.05 mm1.8 mm

Top 68% of catalog designs

Shank separation 0.2 mm — higher than 32% of catalog designs and 51% of its family
Maximum site depth
4.95 mm
0.972 mm51.29 mm

Top 72% of catalog designs

Maximum site depth 4.95 mm — higher than 28% of catalog designs and 32% of its family
Minimum site depth
4.75 mm
0.067 mm44.74 mm

Top 41% of catalog designs

Minimum site depth 4.75 mm — higher than 59% of catalog designs and 55% of its family
Span, x
0.646 mm
0.01 mm6.03 mm

Top 32% of catalog designs

Span, x 0.646 mm — higher than 68% of catalog designs and 69% of its family
Span, y
0.196 mm
0.01 mm10.55 mm

Top 88% of catalog designs

Span, y 0.196 mm — higher than 12% of catalog designs and 16% of its family
Site pitch, x
0.018 µm
0.012 µm0.57 µm

Top 48% of catalog designs

Site pitch, x 0.018 µm — higher than 52% of catalog designs and 49% of its family
Site pitch, y
0.018 µm
0.01 µm1.5 µm

Top 85% of catalog designs

Site pitch, y 0.018 µm — higher than 15% of catalog designs and 53% of its family
Site outline area
0.127 mm²
0.002 mm²28.74 mm²

Top 51% of catalog designs

Site outline area 0.127 mm² — higher than 49% of catalog designs and 48% of its family
Neural interface volume
0.399 mm³
0.149 mm³17.19 mm³

Top 76% of catalog designs

Neural interface volume 0.399 mm³ — higher than 24% of catalog designs and 37% of its family
Site coverage density
252.1 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 48% of catalog designs

Site coverage density 252.1 sites/mm² — higher than 52% of catalog designs and 45% of its family
Brain coverage density
80.17 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 21% of catalog designs

Brain coverage density 80.17 sites/mm³ — higher than 79% of catalog designs and 47% of its family
Tetrode 4-Shank 32-Channel Probe, 5 mmSKU prb_ahc--a4x2_tet_5mm_150_200_121

5 notes · Polytrode and tetrode are two ways to cluster · Site area is the isolation variable · Geometry …

Tetrode 4-Shank 32-Channel Probe, 5 mmSKU prb_ahc--a4x2_tet_5mm_150_200_121

17 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

Tetrode 4-Shank 32-Channel Probe, 5 mmSKU prb_ahc--a4x2_tet_5mm_150_200_121

Cited in 2,342 publications (product line)
