64-site A-Series probe, 4 shanks, 3.6 mm
Four mid-length shanks side by side, with sites spread evenly down each, one per row, for a profile across depth. Among the 369 probe designs in the design space it is mid-range: 64 sites (a common choice — 65 of 369), 3.6 mm shanks (21st percentile of the 366 measured), a 1.36 mm-deep site array (60th percentile), 36 sites/mm² (14th percentile) and a 1.68 mm³ neural interface (87th percentile).
Small sites read a local patch at higher impedance, sharpening single-unit isolation, spaced for a laminar profile. The mid-length shanks reach structures a few millimetres down.
Orders as a probe-plus-package assembly, in 5 package configurations. Silicon 15 µm thick. Z-coat available. Research use only.
a4x16_3_6_3mm50_430_177
12 specs
| Channels | 64 |
|---|---|
| Shanks | 4 |
| Shank length | 3.6 mm |
| Site area | 177 µm² |
| Site pitch | 50 µm |
| Vertical span | 1365 µm |
| Substrate | Silicon |
| Site material | Iridium |
| Thickness | 15 µm |
| Neural interface volume | 1.683 mm³ (higher than 87% of 369 designs) |
| Site coverage density | 35.9 sites/mm² (higher than 14% of 369 designs) |
| Brain coverage density | 38.0 sites/mm³ (higher than 43% of 369 designs) |
Narrow the options with the filters or pick a card, then contact us to order that configuration.
5 options
Configure
Your selection
64-channel 4-shank silicon probe, 3.6 mm — 15 μm, A64
A64Options
5 of 5A64 — 64-ch Samtec
H64 (30 mm cable) — 64-ch Omnetics
H64LP (30 mm cable) — 64-ch Omnetics
X3_64 — 64-ch Molex
X3_H64 (30 mm cable) — 64-ch Molex
Loading the compatible products…
12 metrics
Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.
Top 8% of catalog designs
Sites 64 — higher than 92% of catalog designs and 93% of its familyTop 15% of catalog designs
Shanks 4 — higher than 85% of catalog designs and 82% of its familyTop 79% of catalog designs
Shank length 3.6 mm — higher than 21% of catalog designs and 25% of its familyTop 79% of catalog designs
Maximum site depth 3.56 mm — higher than 21% of catalog designs and 25% of its familyTop 83% of catalog designs
Minimum site depth 2.19 mm — higher than 17% of catalog designs and 18% of its familyTop 15% of catalog designs
Span, x 1.3 mm — higher than 85% of catalog designs and 80% of its familyTop 40% of catalog designs
Span, y 1.36 mm — higher than 60% of catalog designs and 55% of its familyTop 44% of catalog designs
Site pitch, y 0.05 µm — higher than 56% of catalog designs and 42% of its familyTop 11% of catalog designs
Site outline area 1.78 mm² — higher than 89% of catalog designs and 91% of its familyTop 13% of catalog designs
Neural interface volume 1.68 mm³ — higher than 87% of catalog designs and 90% of its familyTop 86% of catalog designs
Site coverage density 35.93 sites/mm² — higher than 14% of catalog designs and 14% of its familyTop 57% of catalog designs
Brain coverage density 38.03 sites/mm³ — higher than 43% of catalog designs and 46% of its family3 notes · Geometry · Construction · Packaging and connector options
