Edge 8-Shank 64-Channel Probe, 5 mm
64-site A-Series probe, 8 shanks, 5 mm, 177 µm², 100 µm pitch
Eight mid-length shanks side by side, closely spaced for coverage within one structure, with sites along the shank's edge, closest to the tissue the probe faces. Among the 369 probe designs in the design space it is mid-range: 64 sites (a common choice — 65 of 369), 5 mm shanks (a common choice — 108 of 366), a 0.71 mm-deep site array (38th percentile), 63 sites/mm² (24th percentile) and a 1.16 mm³ neural interface (78th percentile).
Small sites read a local patch at higher impedance, sharpening single-unit isolation, spaced for a laminar profile. The mid-length shanks reach structures a few millimetres down.
Orders as a probe-plus-package assembly, in 23 package configurations, 2 of them microdrive-compatible. Silicon 15 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.
a8x8_edge_5mm_100_200_177
14 specs
| Channels | 64 |
|---|---|
| Shanks | 8 |
| Shank length | 5 mm |
| Shank separation | 200 µm |
| Site layout | Edge |
| Site area | 177 µm² |
| Site pitch | 100 µm |
| Vertical span | 715 µm |
|---|---|
| Substrate | Silicon |
| Site material | Iridium |
| Thickness | 15 µm |
| Neural interface volume | 1.162 mm³ (higher than 78% of 369 designs) |
| Site coverage density | 63.4 sites/mm² (higher than 24% of 369 designs) |
| Brain coverage density | 55.1 sites/mm³ (higher than 62% of 369 designs) |
Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.
23 options
Configure
Your selection
64-channel 8-shank silicon probe, 5 mm — 15 μm, A64
A64Options
23 of 23A64 — 64-ch Samtec
H64 (30 mm cable) — 64-ch Omnetics
H64_60MM — 64-ch
H64LP (30 mm cable) — 64-ch Omnetics
HC64 (30 mm cable) — 64-ch Omnetics
HC64 — 64-ch Omnetics
HZ64 (30 mm cable) — 64-ch Hirose
HZ64 (60 mm cable) — 64-ch Hirose
OA64LP — 64-ch Samtec
X3_64 — 64-ch Molex
X3_H64 (30 mm cable) — 64-ch Molex
Z64 — 64-ch Hirose
MRH64LP_30MM — 64-ch
MRHC64 — 64-ch Omnetics
OH64LP — 64-ch Omnetics
OA64LP_V2 — 64-ch Samtec
OXA64LP — 64-ch Samtec
AV64 — 64-ch
AVH64 — 64-ch
AVI64 — 64-ch Omnetics
AVIH64 — 64-ch Omnetics
SEACM64 — 64-ch Samtec
EIB64 — 64-ch Molex
Loading the compatible products…
13 metrics
Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.
Top 8% of catalog designs
Sites 64 — higher than 92% of catalog designs and 93% of its familyTop 3% of catalog designs
Shanks 8 — higher than 97% of catalog designs and 94% of its familyTop 48% of catalog designs
Shank length 5 mm — higher than 52% of catalog designs and 61% of its familyTop 68% of catalog designs
Shank separation 0.2 mm — higher than 32% of catalog designs and 32% of its familyTop 62% of catalog designs
Maximum site depth 4.96 mm — higher than 38% of catalog designs and 45% of its familyTop 54% of catalog designs
Minimum site depth 4.24 mm — higher than 46% of catalog designs and 57% of its familyTop 15% of catalog designs
Span, x 1.41 mm — higher than 85% of catalog designs and 81% of its familyTop 62% of catalog designs
Span, y 0.715 mm — higher than 38% of catalog designs and 30% of its familyTop 17% of catalog designs
Site pitch, y 0.1 µm — higher than 83% of catalog designs and 80% of its familyTop 18% of catalog designs
Site outline area 1.01 mm² — higher than 82% of catalog designs and 85% of its familyTop 22% of catalog designs
Neural interface volume 1.16 mm³ — higher than 78% of catalog designs and 82% of its familyTop 76% of catalog designs
Site coverage density 63.39 sites/mm² — higher than 24% of catalog designs and 25% of its familyTop 38% of catalog designs
Brain coverage density 55.1 sites/mm³ — higher than 62% of catalog designs and 71% of its family4 notes · Spending a fixed site budget · Geometry · Construction …
