Grids · ECoG Series

ECoG 128-Channel Grid

128Sites
12µmThickness
11.1mmWidth
Part no.E128-1000-cl80-100
Contents

128-site ECoG grid

A thin polyimide film that lies on the cortical surface and follows its curvature and movement, carrying its recording sites in the film itself. Among the 55 grid designs in the design space it is mid-range: 128 sites (96th percentile), a 7.1 mm site-array span (58th percentile), 1.62 sites/mm² (62nd percentile) and a 44 mm³ neural interface (73rd percentile).

Orders as a grid-plus-package assembly, in 6 package configurations, 1 of them microdrive-compatible. Polyimide 12 µm thick. Research use only.

Also known as

e128_1000_80_100

ECoG 128-Channel GridSKU grd_cog--e128_1000_cl80_100

9 specs

Channels128
Site layoutGrid
Span7100 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Neural interface volume44.080 mm³ (higher than 73% of 55 designs)
Site coverage density1.6 sites/mm² (higher than 62% of 55 designs)
Brain coverage density2.9 sites/mm³ (higher than 62% of 55 designs)
ECoG 128-Channel GridSKU grd_cog--e128_1000_cl80_100

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

6 options

Configure

Compatible Package
All
H128LP — 128-ch Omnetics
HC128 — 128-ch Omnetics
IH128 — 128-ch
X6_128 — 128-ch Panasonic
X6_128L — 128-ch Panasonic
X6_H128 — 128-ch Panasonic

Your selection

128-channel thin-film ECoG grid — HC128, 12 μm
HC128
Compatible Package: HC128 — 128-ch Omnetics
SKUgrd_cog--e128_1000_cl80_100.12um.hc128
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

6 of 6
ECoG 128-Channel GridSKU grd_cog--e128_1000_cl80_100

Loading the compatible products…

ECoG 128-Channel GridSKU grd_cog--e128_1000_cl80_100

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
128
3256

Top 4% of catalog designs

Sites 128 — higher than 96% of catalog designs and 94% of its family
Span, x
11.1 mm
0.1 mm36.5 mm

Top 13% of catalog designs

Span, x 11.1 mm — higher than 87% of catalog designs and 91% of its family
Span, y
7.1 mm
0.26 mm79 mm

Top 42% of catalog designs

Span, y 7.1 mm — higher than 58% of catalog designs and 71% of its family
Site pitch, x
1 µm
0.15 µm6 µm

Top 51% of catalog designs

Site pitch, x 1 µm — higher than 49% of catalog designs and 76% of its family
Site pitch, y
1 µm
0.08 µm5.59 µm

Top 44% of catalog designs

Site pitch, y 1 µm — higher than 56% of catalog designs and 74% of its family
Site outline area
78.81 mm²
0.026 mm²970.7 mm²

Top 27% of catalog designs

Site outline area 78.81 mm² — higher than 73% of catalog designs and 83% of its family
Neural interface volume
44.08 mm³
0.228 mm³501.1 mm³

Top 27% of catalog designs

Neural interface volume 44.08 mm³ — higher than 73% of catalog designs and 83% of its family
Site coverage density
1.62 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 38% of catalog designs

Site coverage density 1.62 sites/mm² — higher than 62% of catalog designs and 43% of its family
Brain coverage density
2.9 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 38% of catalog designs

Brain coverage density 2.9 sites/mm³ — higher than 62% of catalog designs and 43% of its family
ECoG 128-Channel GridSKU grd_cog--e128_1000_cl80_100

5 notes · Epidural or subdural — the decision that shapes the experiment · What holds the array against the brain · Coverage and site layout …

ECoG 128-Channel GridSKU grd_cog--e128_1000_cl80_100

15 links · Surgical Guide: Thin Film Grids - ECoG Implantation · Care, Use and Handling · Choosing an Electrode for Your Experiment …

ECoG 128-Channel GridSKU grd_cog--e128_1000_cl80_100

Cited in 74 publications (product line)
