Grids · ECoG Series

ECoG 252-Channel Grid

252Sites
12µmThickness
6.148mmWidth
Part no.E252-300-cl30-150
Contents

252-site ECoG grid

A thin polyimide film that lies on the cortical surface and follows its curvature and movement, carrying its recording sites in the film itself. Among the 55 grid designs in the design space it is mid-range: 252 sites (98th percentile), a 3.45 mm site-array span (40th percentile), 12 sites/mm² (84th percentile) and a 13 mm³ neural interface (49th percentile).

Orders as a grid-plus-package assembly, in 2 package configurations. Polyimide 12 µm thick. Research use only.

Also known as

e252_300_30_150

ECoG 252-Channel GridSKU grd_cog--e252_300_cl30_150

9 specs

Channels252
Site layoutGrid
Span3449 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Neural interface volume13.128 mm³ (higher than 49% of 55 designs)
Site coverage density11.9 sites/mm² (higher than 84% of 55 designs)
Brain coverage density19.2 sites/mm³ (higher than 89% of 55 designs)
ECoG 252-Channel GridSKU grd_cog--e252_300_cl30_150

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

2 options

Configure

Compatible Package
All
AVH256 — 256-ch
IH256 — 256-ch

Your selection

252-channel thin-film ECoG grid — 12 μm, AVH256
AVH256
Compatible Package: AVH256 — 256-ch
SKUgrd_cog--e252_300_cl30_150.12um.avh256
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

2 of 2
ECoG 252-Channel GridSKU grd_cog--e252_300_cl30_150

Loading the compatible products…

ECoG 252-Channel GridSKU grd_cog--e252_300_cl30_150

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
252
3256

Top 2% of catalog designs

Sites 252 — higher than 98% of catalog designs and 97% of its family
Span, x
6.15 mm
0.1 mm36.5 mm

Top 51% of catalog designs

Span, x 6.15 mm — higher than 49% of catalog designs and 66% of its family
Span, y
3.45 mm
0.26 mm79 mm

Top 60% of catalog designs

Span, y 3.45 mm — higher than 40% of catalog designs and 57% of its family
Site pitch, x
0.3 µm
0.15 µm6 µm

Top 83% of catalog designs

Site pitch, x 0.3 µm — higher than 17% of catalog designs and 26% of its family
Site pitch, y
0.3 µm
0.08 µm5.59 µm

Top 81% of catalog designs

Site pitch, y 0.3 µm — higher than 19% of catalog designs and 26% of its family
Site outline area
21.21 mm²
0.026 mm²970.7 mm²

Top 51% of catalog designs

Site outline area 21.21 mm² — higher than 49% of catalog designs and 66% of its family
Neural interface volume
13.13 mm³
0.228 mm³501.1 mm³

Top 51% of catalog designs

Neural interface volume 13.13 mm³ — higher than 49% of catalog designs and 66% of its family
Site coverage density
11.88 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 16% of catalog designs

Site coverage density 11.88 sites/mm² — higher than 84% of catalog designs and 77% of its family
Brain coverage density
19.2 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 11% of catalog designs

Brain coverage density 19.2 sites/mm³ — higher than 89% of catalog designs and 83% of its family
ECoG 252-Channel GridSKU grd_cog--e252_300_cl30_150

5 notes · Epidural or subdural — the decision that shapes the experiment · What holds the array against the brain · Coverage and site layout …

ECoG 252-Channel GridSKU grd_cog--e252_300_cl30_150

15 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

ECoG 252-Channel GridSKU grd_cog--e252_300_cl30_150

Cited in 74 publications (product line)
