Grids · ECoG Series

ECoG 32-Channel Grid

32Sites
12µmThickness
6.1mmWidth
1,963µm²Site Area
Part no.E32-1000-cl20-50-100
Contents

32-site ECoG grid, 50 µm sites, 6.1 × 4.1 mm

A thin polyimide film that lies on the cortical surface and follows its curvature and movement, carrying small sites that read a local patch at high impedance, on a short cable for a compact head end. Among the 55 grid designs in the design space it is mid-range: 32 sites (a common choice — 16 of 55), a 4.1 mm site-array span (44th percentile), 1.28 sites/mm² (51st percentile) and a 15 mm³ neural interface (55th percentile).

Orders as a grid-plus-package assembly, in 6 package configurations, 3 of them microdrive-compatible. Polyimide 12 µm thick. 20 mm cable. Research use only.

Also known as

e32_1000_20_50/100

ECoG 32-Channel GridSKU grd_cog--e32_1000_cl20_50_100

Estimated geometry — the site layout is not from a measured design file, so geometry-derived values are approximate.

11 specs

Channels32
Site layoutGrid
Site area1,963 µm²
Span4100 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Site geometryEstimated from the catalog drawing and similar designs
Neural interface volume15.180 mm³ (higher than 55% of 55 designs)
Site coverage density1.3 sites/mm² (higher than 51% of 55 designs)
Brain coverage density2.1 sites/mm³ (higher than 53% of 55 designs)
ECoG 32-Channel GridSKU grd_cog--e32_1000_cl20_50_100

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

6 options

Configure

Compatible Package
All
H32 — 32-ch Omnetics
HC32 — 32-ch Omnetics
HZ32 — 32-ch Hirose
MRH32 — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
X3_H32 — 32-ch Molex

Your selection

32-channel thin-film ECoG grid — H32, 12 μm
H32
Compatible Package: H32 — 32-ch Omnetics
SKUgrd_cog--e32_1000_cl20_50_100.12um.h32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

6 of 6
ECoG 32-Channel GridSKU grd_cog--e32_1000_cl20_50_100

Loading the compatible products…

ECoG 32-Channel GridSKU grd_cog--e32_1000_cl20_50_100

Estimated geometry — the site layout is not from a measured design file, so geometry-derived values are approximate.

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
32
3256

Top 33% of catalog designs

Sites 32 — higher than 67% of catalog designs and 60% of its family
Span, x
6.1 mm
0.1 mm36.5 mm

Top 53% of catalog designs

Span, x 6.1 mm — higher than 47% of catalog designs and 63% of its family
Span, y
4.1 mm
0.26 mm79 mm

Top 56% of catalog designs

Span, y 4.1 mm — higher than 44% of catalog designs and 63% of its family
Site pitch, x
1 µm
0.15 µm6 µm

Top 51% of catalog designs

Site pitch, x 1 µm — higher than 49% of catalog designs and 76% of its family
Site pitch, y
2 µm
0.08 µm5.59 µm

Top 22% of catalog designs

Site pitch, y 2 µm — higher than 78% of catalog designs and 88% of its family
Site outline area
25.01 mm²
0.026 mm²970.7 mm²

Top 45% of catalog designs

Site outline area 25.01 mm² — higher than 55% of catalog designs and 74% of its family
Neural interface volume
15.18 mm³
0.228 mm³501.1 mm³

Top 45% of catalog designs

Neural interface volume 15.18 mm³ — higher than 55% of catalog designs and 74% of its family
Site coverage density
1.28 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 49% of catalog designs

Site coverage density 1.28 sites/mm² — higher than 51% of catalog designs and 31% of its family
Brain coverage density
2.11 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 47% of catalog designs

Brain coverage density 2.11 sites/mm³ — higher than 53% of catalog designs and 31% of its family
ECoG 32-Channel GridSKU grd_cog--e32_1000_cl20_50_100

5 notes · Epidural or subdural — the decision that shapes the experiment · What holds the array against the brain · Coverage and site layout …

ECoG 32-Channel GridSKU grd_cog--e32_1000_cl20_50_100

15 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

ECoG 32-Channel GridSKU grd_cog--e32_1000_cl20_50_100

Cited in 74 publications (product line)
