Grids · ECoG Series

ECoG 32-Channel Grid

32Sites
12µmThickness
3.099mmWidth
7,854µm²Site Area
Part no.E32-600-cl10-100
Contents

32-site ECoG grid, 100 µm sites, 3.1 × 3.1 mm

A thin polyimide film that lies on the cortical surface and follows its curvature and movement, carrying small sites that read a local patch at high impedance. Among the 55 grid designs in the design space it is mid-range: 32 sites (a common choice — 16 of 55), a 3.1 mm site-array span (35th percentile), 3.33 sites/mm² (65th percentile) and a 6.48 mm³ neural interface (31st percentile).

Orders as a grid-plus-package assembly, in 6 package configurations, 3 of them microdrive-compatible. Polyimide 12 µm thick. Research use only.

Also known as

e32_600_10_100

ECoG 32-Channel GridSKU grd_cog--e32_600_cl10_100

10 specs

Channels32
Site layoutGrid
Site area7,854 µm²
Span3099 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Neural interface volume6.477 mm³ (higher than 31% of 55 designs)
Site coverage density3.3 sites/mm² (higher than 65% of 55 designs)
Brain coverage density4.9 sites/mm³ (higher than 65% of 55 designs)
ECoG 32-Channel GridSKU grd_cog--e32_600_cl10_100

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

6 options

Configure

Compatible Package
All
H32 — 32-ch Omnetics
HC32 — 32-ch Omnetics
HZ32 — 32-ch Hirose
MRH32 — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
X3_H32 — 32-ch Molex

Your selection

32-channel thin-film ECoG grid — H32, 12 μm
H32
Compatible Package: H32 — 32-ch Omnetics
SKUgrd_cog--e32_600_cl10_100.12um.h32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

6 of 6
ECoG 32-Channel GridSKU grd_cog--e32_600_cl10_100

Loading the compatible products…

ECoG 32-Channel GridSKU grd_cog--e32_600_cl10_100

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
32
3256

Top 33% of catalog designs

Sites 32 — higher than 67% of catalog designs and 60% of its family
Span, x
3.1 mm
0.1 mm36.5 mm

Top 67% of catalog designs

Span, x 3.1 mm — higher than 33% of catalog designs and 49% of its family
Span, y
3.1 mm
0.26 mm79 mm

Top 65% of catalog designs

Span, y 3.1 mm — higher than 35% of catalog designs and 49% of its family
Site pitch, x
0.6 µm
0.15 µm6 µm

Top 64% of catalog designs

Site pitch, x 0.6 µm — higher than 36% of catalog designs and 56% of its family
Site pitch, y
0.6 µm
0.08 µm5.59 µm

Top 59% of catalog designs

Site pitch, y 0.6 µm — higher than 41% of catalog designs and 56% of its family
Site outline area
9.6 mm²
0.026 mm²970.7 mm²

Top 67% of catalog designs

Site outline area 9.6 mm² — higher than 33% of catalog designs and 49% of its family
Neural interface volume
6.48 mm³
0.228 mm³501.1 mm³

Top 69% of catalog designs

Neural interface volume 6.48 mm³ — higher than 31% of catalog designs and 46% of its family
Site coverage density
3.33 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 35% of catalog designs

Site coverage density 3.33 sites/mm² — higher than 65% of catalog designs and 49% of its family
Brain coverage density
4.94 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 35% of catalog designs

Brain coverage density 4.94 sites/mm³ — higher than 65% of catalog designs and 49% of its family
ECoG 32-Channel GridSKU grd_cog--e32_600_cl10_100

5 notes · Epidural or subdural — the decision that shapes the experiment · What holds the array against the brain · Coverage and site layout …

ECoG 32-Channel GridSKU grd_cog--e32_600_cl10_100

15 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

ECoG 32-Channel GridSKU grd_cog--e32_600_cl10_100

Cited in 74 publications (product line)
