Grids · ECoG Series

ECoG 4-Channel Grid

4Sites
12µmThickness
9.5mmWidth
196,350µm²Site Area
Part no.E4-3000-cl40-500
Contents

4-site ECoG grid

A thin polyimide film that lies on the cortical surface and follows its curvature and movement, carrying large sites that average a broad patch at low impedance, on a long cable for routing to the connector. Among the 55 grid designs in the design space it is in the lower quartile: 4 sites (4th percentile), a 0.5 mm site-array span (5th percentile), 0.84 sites/mm² (45th percentile) and a 5 mm³ neural interface (24th percentile).

Orders as a grid-plus-package assembly, in 5 package configurations, 2 of them microdrive-compatible. Polyimide 12 µm thick. 40 mm cable. Research use only.

Also known as

e4_3000_40_500

ECoG 4-Channel GridSKU grd_cog--e4_3000_cl40_500

Estimated geometry — the site layout is not from a measured design file, so geometry-derived values are approximate.

11 specs

Channels4
Site layoutGrid
Site area196,350 µm²
Span500 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Site geometryEstimated from the catalog drawing and similar designs
Neural interface volume5.000 mm³ (higher than 24% of 55 designs)
Site coverage density0.8 sites/mm² (higher than 45% of 55 designs)
Brain coverage density0.8 sites/mm³ (higher than 35% of 55 designs)
ECoG 4-Channel GridSKU grd_cog--e4_3000_cl40_500

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

5 options

Configure

Compatible Package
All
H16 (21 mm cable) — 16-ch Omnetics
HC16 — 16-ch Omnetics
HZ16 — 16-ch Hirose
MRH16 — 16-ch Omnetics
X3_H16 — 16-ch Molex

Your selection

4-channel thin-film ECoG grid — H16_21MM, 12 μm
H16_21MM
Compatible Package: H16 (21 mm cable) — 16-ch Omnetics
SKUgrd_cog--e4_3000_cl40_500.12um.h16_21mm
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.
