Grids · ECoG Series

ECoG 64-Channel Grid

64Sites
12µmThickness
1.639mmWidth
1,257µm²Site Area
Part no.E64-400-cl60-40
Contents

64-site ECoG grid, 40 µm sites

A thin polyimide film that lies on the cortical surface and follows its curvature and movement, carrying small sites that read a local patch at high impedance. Among the 55 grid designs in the design space it is mid-range: 64 sites (a common choice — 9 of 55), a 4.84 mm site-array span (49th percentile), 8.07 sites/mm² (80th percentile) and a 5.71 mm³ neural interface (25th percentile).

Orders as a grid-plus-package assembly, in 5 package configurations, 3 of them microdrive-compatible. Polyimide 12 µm thick. Research use only.

Also known as

e64_400_60_40

ECoG 64-Channel GridSKU grd_cog--e64_400_cl60_40

10 specs

Channels64
Site layoutGrid
Site area1,257 µm²
Span4840 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Neural interface volume5.712 mm³ (higher than 25% of 55 designs)
Site coverage density8.1 sites/mm² (higher than 80% of 55 designs)
Brain coverage density11.2 sites/mm³ (higher than 82% of 55 designs)
ECoG 64-Channel GridSKU grd_cog--e64_400_cl60_40

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

5 options

Configure

Compatible Package
All
H64 — 64-ch Omnetics
H64LP — 64-ch Omnetics
HC64 — 64-ch Omnetics
HZ64 — 64-ch Hirose
X3_H64 — 64-ch Molex

Your selection

64-channel thin-film ECoG grid — H64LP, 12 μm
H64LP
Compatible Package: H64LP — 64-ch Omnetics
SKUgrd_cog--e64_400_cl60_40.12um.h64lp
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

5 of 5
ECoG 64-Channel GridSKU grd_cog--e64_400_cl60_40

Loading the compatible products…

ECoG 64-Channel GridSKU grd_cog--e64_400_cl60_40

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
64
3256

Top 16% of catalog designs

Sites 64 — higher than 84% of catalog designs and 77% of its family
Span, x
1.64 mm
0.1 mm36.5 mm

Top 82% of catalog designs

Span, x 1.64 mm — higher than 18% of catalog designs and 26% of its family
Span, y
4.84 mm
0.26 mm79 mm

Top 51% of catalog designs

Span, y 4.84 mm — higher than 49% of catalog designs and 66% of its family
Site pitch, x
0.4 µm
0.15 µm6 µm

Top 81% of catalog designs

Site pitch, x 0.4 µm — higher than 19% of catalog designs and 29% of its family
Site pitch, y
0.4 µm
0.08 µm5.59 µm

Top 76% of catalog designs

Site pitch, y 0.4 µm — higher than 24% of catalog designs and 32% of its family
Site outline area
7.93 mm²
0.026 mm²970.7 mm²

Top 71% of catalog designs

Site outline area 7.93 mm² — higher than 29% of catalog designs and 43% of its family
Neural interface volume
5.71 mm³
0.228 mm³501.1 mm³

Top 75% of catalog designs

Neural interface volume 5.71 mm³ — higher than 25% of catalog designs and 37% of its family
Site coverage density
8.07 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 20% of catalog designs

Site coverage density 8.07 sites/mm² — higher than 80% of catalog designs and 71% of its family
Brain coverage density
11.2 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 18% of catalog designs

Brain coverage density 11.2 sites/mm³ — higher than 82% of catalog designs and 74% of its family
ECoG 64-Channel GridSKU grd_cog--e64_400_cl60_40

5 notes · Epidural or subdural — the decision that shapes the experiment · What holds the array against the brain · Coverage and site layout …

ECoG 64-Channel GridSKU grd_cog--e64_400_cl60_40

15 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

ECoG 64-Channel GridSKU grd_cog--e64_400_cl60_40

Cited in 74 publications (product line)
