Neural Probes · A-Series (Isomura)

Tetrode/Linear 3-Shank 33-Channel Probe, 7 mm

33Sites
3Shanks
7mmShank Length
22.5µmSite Pitch
Part no.Iso32-3X-tet-Lin-7mm
Contents

33-site Isomura probe

Three long shanks side by side, spread for lateral coverage across columns, with tetrode groups along a linear run, isolation at set depths with a profile between. Among the 369 probe designs in the design space it is mid-range: 33 sites (74th percentile), 7 mm shanks (64th percentile of the 366 measured), a 0.52 mm-deep site array (29th percentile), 103 sites/mm² (35th percentile) and a 0.57 mm³ neural interface (45th percentile).

Mid-sized sites balance unit isolation against field-potential pickup, packed densely enough to track a unit across neighbouring sites. The long shanks reach deep targets.

Orders as a probe-plus-package assembly, in 27 package configurations, 5 of them microdrive-compatible. Silicon 15 or 50 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.

Also known as

iso32_3x_tet_lin_7mm

Tetrode/Linear 3-Shank 33-Channel Probe, 7 mmSKU prb_ais--iso32_3x_tet_lin_7mm

14 specs

Channels33
Shanks3
Shank length7 mm
Shank separation270 µm
Site layoutTetrode/linear
Site area305 µm²
Site pitch22.5 µm
Vertical span520 µm
SubstrateSilicon
Site materialIridium
Thickness15, 50 µm
Neural interface volume0.570 mm³ (higher than 45% of 369 designs)
Site coverage density102.9 sites/mm² (higher than 35% of 369 designs)
Brain coverage density57.9 sites/mm³ (higher than 63% of 369 designs)
Tetrode/Linear 3-Shank 33-Channel Probe, 7 mmSKU prb_ais--iso32_3x_tet_lin_7mm

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

54 options

Configure

Substrate Thickness
All
15 μm
50 μm
Compatible Package
All
A32 — 32-ch Samtec
CM32 — 32-ch Omnetics
F64 — 64-ch Omnetics
FH64 — 64-ch Omnetics
H32 — 32-ch Omnetics
H32 (200 mm cable) — 32-ch Omnetics
H32 (21 mm cable) — 32-ch Omnetics
H32 (50 mm cable) — 32-ch Omnetics
HC32 — 32-ch Omnetics
HZ32 — 32-ch Hirose
MRCM16PB32 — 16-ch
MRCM32 — 32-ch
MRH32 — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
MROCM32LP — 32-ch Omnetics
OA32LP — 32-ch Samtec
OA32LP_V2 — 32-ch Samtec
OCM32LP — 32-ch Omnetics
OH32LP — 32-ch Omnetics
OHZ32LP — 32-ch Hirose
OXA32LP — 32-ch Samtec
OXCM32LP — 32-ch Omnetics
OXH32LP_21MM — 32-ch
OZ32LP — 32-ch Hirose
X3_32 — 32-ch Molex
X3_H32 — 32-ch Molex
Z32 — 32-ch Hirose

Your selection

33-channel 3-shank silicon probe, 7 mm — 15 μm, A32
A32
Substrate Thickness: 15 μm
Compatible Package: A32 — 32-ch Samtec
SKUprb_ais--iso32_3x_tet_lin_7mm.15um.a32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

54 of 54
Tetrode/Linear 3-Shank 33-Channel Probe, 7 mmSKU prb_ais--iso32_3x_tet_lin_7mm

Loading the compatible products…

Tetrode/Linear 3-Shank 33-Channel Probe, 7 mmSKU prb_ais--iso32_3x_tet_lin_7mm

14 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
33
41024

Top 26% of catalog designs

Sites 33 — higher than 74% of catalog designs and 50% of its family
Shanks
3
116

Top 45% of catalog designs

Shanks 3 — higher than 55% of catalog designs and 60% of its family
Shank length
7 mm
1 mm60 mm

Top 36% of catalog designs

Shank length 7 mm — higher than 64% of catalog designs and 43% of its family
Shank separation
0.27 mm
0.05 mm1.8 mm

Top 31% of catalog designs

Shank separation 0.27 mm — higher than 69% of catalog designs and 38% of its family
Maximum site depth
6.99 mm
0.972 mm51.29 mm

Top 36% of catalog designs

Maximum site depth 6.99 mm — higher than 64% of catalog designs and 29% of its family
Minimum site depth
6.47 mm
0.067 mm44.74 mm

Top 32% of catalog designs

Minimum site depth 6.47 mm — higher than 68% of catalog designs and 57% of its family
Span, x
0.617 mm
0.01 mm6.03 mm

Top 38% of catalog designs

Span, x 0.617 mm — higher than 62% of catalog designs and 50% of its family
Span, y
0.52 mm
0.01 mm10.55 mm

Top 71% of catalog designs

Span, y 0.52 mm — higher than 29% of catalog designs and 20% of its family
Site pitch, x
0.016 µm
0.012 µm0.57 µm

Top 88% of catalog designs

Site pitch, x 0.016 µm — higher than 12% of catalog designs and 70% of its family
Site pitch, y
0.022 µm
0.01 µm1.5 µm

Top 77% of catalog designs

Site pitch, y 0.022 µm — higher than 23% of catalog designs and 80% of its family
Site outline area
0.321 mm²
0.002 mm²28.74 mm²

Top 40% of catalog designs

Site outline area 0.321 mm² — higher than 60% of catalog designs and 40% of its family
Neural interface volume
0.57 mm³
0.149 mm³17.19 mm³

Top 55% of catalog designs

Neural interface volume 0.57 mm³ — higher than 45% of catalog designs and 20% of its family
Site coverage density
102.9 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 65% of catalog designs · largest in its family

Site coverage density 102.9 sites/mm² — higher than 35% of catalog designs and 100% of its family (the largest in its family, 10 designs)
Brain coverage density
57.95 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 37% of catalog designs · largest in its family

Brain coverage density 57.95 sites/mm³ — higher than 63% of catalog designs and 100% of its family (the largest in its family, 10 designs)
