Neural Probes · A-Series (Isomura)

Tetrode 4-Shank 64-Channel Probe, 10 mm

64Sites
4Shanks
10mmShank Length
17.8µmSite Pitch
Part no.Iso32-4X-tet-10mm
Contents

64-site Isomura probe, 4 shanks, 10 mm

Four long shanks side by side, spread for lateral coverage across columns, with sites grouped in tetrodes at intervals, for unit isolation at set depths. Among the 369 probe designs in the design space it is mid-range: 64 sites (a common choice — 65 of 369), 10 mm shanks (a common choice — 80 of 366), a 1.09 mm-deep site array (56th percentile), 58 sites/mm² (22nd percentile) and a 1.2 mm³ neural interface (79th percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The long shanks reach deep targets.

Orders as a probe-plus-package assembly, in 24 package configurations, 3 of them microdrive-compatible. Silicon 50 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.

Also known as

iso32_4x_tet_10mm

Tetrode 4-Shank 64-Channel Probe, 10 mmSKU prb_ais--iso32_4x_tet_10mm

14 specs

Channels64
Shanks4
Shank length10 mm
Shank separation300 µm
Site layoutTetrode
Site area172 µm²
Site pitch17.799 µm
Vertical span1090 µm
SubstrateSilicon
Site materialIridium
Thickness50 µm
Neural interface volume1.204 mm³ (higher than 79% of 369 designs)
Site coverage density57.9 sites/mm² (higher than 22% of 369 designs)
Brain coverage density53.1 sites/mm³ (higher than 60% of 369 designs)
Tetrode 4-Shank 64-Channel Probe, 10 mmSKU prb_ais--iso32_4x_tet_10mm

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

24 options

Configure

Compatible Package
All
A32 — 32-ch Samtec
CM32 — 32-ch Omnetics
F64 — 64-ch Omnetics
FH64 — 64-ch Omnetics
H32 (21 mm cable) — 32-ch Omnetics
HC32 — 32-ch Omnetics
HZ32 — 32-ch Hirose
MRCM16PB32 — 16-ch
MRCM32 — 32-ch
MRH32 — 32-ch Omnetics
MRHC32 — 32-ch Omnetics
MROCM32LP — 32-ch Omnetics
OA32LP — 32-ch Samtec
OA32LP_V2 — 32-ch Samtec
OCM32LP — 32-ch Omnetics
OH32LP — 32-ch Omnetics
OHZ32LP — 32-ch Hirose
OXA32LP — 32-ch Samtec
OXCM32LP — 32-ch Omnetics
OXH32LP_21MM — 32-ch
OZ32LP — 32-ch Hirose
X3_32 — 32-ch Molex
X3_H32 (21 mm cable) — 32-ch Molex
Z32 — 32-ch Hirose

Your selection

64-channel 4-shank silicon probe, 10 mm — 50 μm, A32
A32
Compatible Package: A32 — 32-ch Samtec
SKUprb_ais--iso32_4x_tet_10mm.50um.a32
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

24 of 24
Tetrode 4-Shank 64-Channel Probe, 10 mmSKU prb_ais--iso32_4x_tet_10mm

Loading the compatible products…

Tetrode 4-Shank 64-Channel Probe, 10 mmSKU prb_ais--iso32_4x_tet_10mm

14 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
64
41024

Top 8% of catalog designs

Sites 64 — higher than 92% of catalog designs and 90% of its family
Shanks
4
116

Top 15% of catalog designs · largest in its family

Shanks 4 — higher than 85% of catalog designs and 100% of its family (the largest in its family, 10 designs)
Shank length
10 mm
1 mm60 mm

Top 10% of catalog designs

Shank length 10 mm — higher than 90% of catalog designs and 86% of its family
Shank separation
0.3 mm
0.05 mm1.8 mm

Top 27% of catalog designs

Shank separation 0.3 mm — higher than 73% of catalog designs and 75% of its family
Maximum site depth
9.99 mm
0.972 mm51.29 mm

Top 11% of catalog designs

Maximum site depth 9.99 mm — higher than 89% of catalog designs and 86% of its family
Minimum site depth
8.9 mm
0.067 mm44.74 mm

Top 18% of catalog designs · largest in its family

Minimum site depth 8.9 mm — higher than 82% of catalog designs and 100% of its family (the largest in its family, 7 designs)
Span, x
1.01 mm
0.01 mm6.03 mm

Top 25% of catalog designs · largest in its family

Span, x 1.01 mm — higher than 75% of catalog designs and 100% of its family (the largest in its family, 10 designs)
Span, y
1.09 mm
0.01 mm10.55 mm

Top 44% of catalog designs

Span, y 1.09 mm — higher than 56% of catalog designs and 70% of its family
Site pitch, x
0.012 µm
0.012 µm0.57 µm

Top 95% of catalog designs

Site pitch, x 0.012 µm — higher than 5% of catalog designs and 40% of its family
Site pitch, y
0.018 µm
0.01 µm1.5 µm

Top 84% of catalog designs

Site pitch, y 0.018 µm — higher than 16% of catalog designs and 50% of its family
Site outline area
1.11 mm²
0.002 mm²28.74 mm²

Top 17% of catalog designs

Site outline area 1.11 mm² — higher than 83% of catalog designs and 90% of its family
Neural interface volume
1.2 mm³
0.149 mm³17.19 mm³

Top 21% of catalog designs

Neural interface volume 1.2 mm³ — higher than 79% of catalog designs and 70% of its family
Site coverage density
57.86 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 78% of catalog designs

Site coverage density 57.86 sites/mm² — higher than 22% of catalog designs and 60% of its family
Brain coverage density
53.15 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 40% of catalog designs

Brain coverage density 53.15 sites/mm³ — higher than 60% of catalog designs and 70% of its family
Tetrode 4-Shank 64-Channel Probe, 10 mmSKU prb_ais--iso32_4x_tet_10mm

5 notes · Shank pitch has to match the anatomy · The larger sites are deliberate · Geometry …

Tetrode 4-Shank 64-Channel Probe, 10 mmSKU prb_ais--iso32_4x_tet_10mm

15 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

Tetrode 4-Shank 64-Channel Probe, 10 mmSKU prb_ais--iso32_4x_tet_10mm

Cited in 2,342 publications (product line)
