Neural Probes · A-Series (Isomura)

Tetrode/Linear 4-Shank 65-Channel Probe, 10 mm

65Sites
4Shanks
10mmShank Length
17.8µmSite Pitch
Part no.Iso64-4X-tet-Lin-10mm
Contents

65-site Isomura probe

Four long shanks side by side, spread for lateral coverage across columns, with tetrode groups along a linear run, isolation at set depths with a profile between. Among the 369 probe designs in the design space it is mid-range: 65 sites (92nd percentile), 10 mm shanks (a common choice — 80 of 366), a 1.09 mm-deep site array (56th percentile), 59 sites/mm² (23rd percentile) and a 1.2 mm³ neural interface (79th percentile).

Small sites read a local patch at higher impedance, sharpening single-unit isolation, packed densely enough to track a unit across neighbouring sites. The long shanks reach deep targets.

Orders as a probe-plus-package assembly, in 22 package configurations, 3 of them microdrive-compatible. Silicon 50 µm thick. Z-coat available. Optical stimulation runs from a separate laser or LED source. Research use only.

Also known as

iso64_4x_tet_lin_10mm

Tetrode/Linear 4-Shank 65-Channel Probe, 10 mmSKU prb_ais--iso64_4x_tet_lin_10mm

14 specs

Channels65
Shanks4
Shank length10 mm
Shank separation300 µm
Site layoutTetrode/linear
Site area172 µm²
Site pitch17.799 µm
Vertical span1090 µm
SubstrateSilicon
Site materialIridium
Thickness50 µm
Neural interface volume1.204 mm³ (higher than 79% of 369 designs)
Site coverage density58.8 sites/mm² (higher than 23% of 369 designs)
Brain coverage density54.0 sites/mm³ (higher than 61% of 369 designs)
Tetrode/Linear 4-Shank 65-Channel Probe, 10 mmSKU prb_ais--iso64_4x_tet_lin_10mm

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

22 options

Configure

Compatible Package
All
A64 — 64-ch Samtec
AV64 — 64-ch
AVH64 — 64-ch
AVI64 — 64-ch Omnetics
AVIH64 — 64-ch Omnetics
EIB64 — 64-ch Molex
F128 — 128-ch Omnetics
FH128 — 128-ch Omnetics
H64 — 64-ch Omnetics
H64LP (30 mm cable) — 64-ch Omnetics
HC64 — 64-ch Omnetics
HZ64 — 64-ch Hirose
MRH64LP_30MM — 64-ch
MRHC64 — 64-ch Omnetics
OA64LP — 64-ch Samtec
OA64LP_V2 — 64-ch Samtec
OH64LP — 64-ch Omnetics
OXA64LP — 64-ch Samtec
SEACM64 — 64-ch Samtec
X3_64 — 64-ch Molex
X3_H64 (30 mm cable) — 64-ch Molex
Z64 — 64-ch Hirose

Your selection

65-channel 4-shank silicon probe, 10 mm — 50 μm, A64
A64
Compatible Package: A64 — 64-ch Samtec
SKUprb_ais--iso64_4x_tet_lin_10mm.50um.a64
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

22 of 22
Tetrode/Linear 4-Shank 65-Channel Probe, 10 mmSKU prb_ais--iso64_4x_tet_lin_10mm

Loading the compatible products…

Tetrode/Linear 4-Shank 65-Channel Probe, 10 mmSKU prb_ais--iso64_4x_tet_lin_10mm

14 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
65
41024

Top 8% of catalog designs · largest in its family

Sites 65 — higher than 92% of catalog designs and 100% of its family (the largest in its family, 10 designs)
Shanks
4
116

Top 15% of catalog designs · largest in its family

Shanks 4 — higher than 85% of catalog designs and 100% of its family (the largest in its family, 10 designs)
Shank length
10 mm
1 mm60 mm

Top 10% of catalog designs

Shank length 10 mm — higher than 90% of catalog designs and 86% of its family
Shank separation
0.3 mm
0.05 mm1.8 mm

Top 27% of catalog designs

Shank separation 0.3 mm — higher than 73% of catalog designs and 75% of its family
Maximum site depth
9.99 mm
0.972 mm51.29 mm

Top 11% of catalog designs

Maximum site depth 9.99 mm — higher than 89% of catalog designs and 86% of its family
Minimum site depth
8.9 mm
0.067 mm44.74 mm

Top 18% of catalog designs · largest in its family

Minimum site depth 8.9 mm — higher than 82% of catalog designs and 100% of its family (the largest in its family, 7 designs)
Span, x
1.01 mm
0.01 mm6.03 mm

Top 25% of catalog designs · largest in its family

Span, x 1.01 mm — higher than 75% of catalog designs and 100% of its family (the largest in its family, 10 designs)
Span, y
1.09 mm
0.01 mm10.55 mm

Top 44% of catalog designs

Span, y 1.09 mm — higher than 56% of catalog designs and 70% of its family
Site pitch, x
0.012 µm
0.012 µm0.57 µm

Top 95% of catalog designs

Site pitch, x 0.012 µm — higher than 5% of catalog designs and 40% of its family
Site pitch, y
0.018 µm
0.01 µm1.5 µm

Top 84% of catalog designs

Site pitch, y 0.018 µm — higher than 16% of catalog designs and 50% of its family
Site outline area
1.11 mm²
0.002 mm²28.74 mm²

Top 17% of catalog designs

Site outline area 1.11 mm² — higher than 83% of catalog designs and 90% of its family
Neural interface volume
1.2 mm³
0.149 mm³17.19 mm³

Top 21% of catalog designs

Neural interface volume 1.2 mm³ — higher than 79% of catalog designs and 70% of its family
Site coverage density
58.77 sites/mm²
1.66 sites/mm²3047.2 sites/mm²

Top 77% of catalog designs

Site coverage density 58.77 sites/mm² — higher than 23% of catalog designs and 70% of its family
Brain coverage density
53.98 sites/mm³
2.49 sites/mm³393.9 sites/mm³

Top 39% of catalog designs

Brain coverage density 53.98 sites/mm³ — higher than 61% of catalog designs and 80% of its family
Tetrode/Linear 4-Shank 65-Channel Probe, 10 mmSKU prb_ais--iso64_4x_tet_lin_10mm

5 notes · Shank pitch has to match the anatomy · The larger sites are deliberate · Geometry …

Tetrode/Linear 4-Shank 65-Channel Probe, 10 mmSKU prb_ais--iso64_4x_tet_lin_10mm

15 links · Care, Use and Handling · Choosing an Electrode for Your Experiment · How an Electrode Records Neural Activity …

Tetrode/Linear 4-Shank 65-Channel Probe, 10 mmSKU prb_ais--iso64_4x_tet_lin_10mm

Cited in 2,342 publications (product line)
