Grids · EEG Series

EEG 16-Channel Grid

16Sites
12µmThickness
11.09mmWidth
196,350µm²Site Area
Part no.Eeg-r-16-cl10-func
Contents

16-site EEG grid, 11.1 × 6.5 mm

A thin polyimide film that sits on the outside of the skull, with no bone removed and no dura opened, carrying large sites that average a broad patch at low impedance. Among the 55 grid designs in the design space it is mid-range: 14 sites (11th percentile), a 6.5 mm site-array span (55th percentile), 0.19 sites/mm² (16th percentile) and a 41 mm³ neural interface (69th percentile).

Orders as a grid-plus-package assembly, in 6 package configurations, 3 of them microdrive-compatible. Polyimide 12 µm thick. Research use only.

Also known as

eeg_rat_16_10_functional · eeg_rat_16_10_fxn · Rat EEG16_functional-H16

EEG 16-Channel GridSKU grd_eeg--eeg_r_16_cl10_func

10 specs

Channels16
Site layoutGrid
Site area196,350 µm²
Span6497 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Neural interface volume40.565 mm³ (higher than 69% of 55 designs)
Site coverage density0.2 sites/mm² (higher than 16% of 55 designs)
Brain coverage density0.3 sites/mm³ (higher than 16% of 55 designs)
EEG 16-Channel GridSKU grd_eeg--eeg_r_16_cl10_func

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

6 options

Configure

Compatible Package
All
H16 — 16-ch Omnetics
H16 (21 mm cable) — 16-ch Omnetics
HC16 — 16-ch Omnetics
HZ16 — 16-ch Hirose
MRH16 — 16-ch Omnetics
X3_H16 — 16-ch Molex

Your selection

16-channel thin-film EEG grid — 12 μm, H16_T_21MM
H16_T_21MM
Compatible Package: H16 (21 mm cable) — 16-ch Omnetics
SKUgrd_eeg--eeg_r_16_cl10_func.12um.h16t
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

6 of 6
EEG 16-Channel GridSKU grd_eeg--eeg_r_16_cl10_func

Loading the compatible products…

EEG 16-Channel GridSKU grd_eeg--eeg_r_16_cl10_func

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
14
3256

Top 89% of catalog designs

Sites 14 — higher than 11% of catalog designs and 22% of its family
Span, x
11.09 mm
0.1 mm36.5 mm

Top 15% of catalog designs · largest in its family

Span, x 11.09 mm — higher than 85% of catalog designs and 100% of its family (the largest in its family, 9 designs)
Span, y
6.5 mm
0.26 mm79 mm

Top 45% of catalog designs

Span, y 6.5 mm — higher than 55% of catalog designs and 33% of its family
Site pitch, x
2 µm
0.15 µm6 µm

Top 25% of catalog designs

Site pitch, x 2 µm — higher than 75% of catalog designs and 78% of its family
Site pitch, y
5.59 µm
0.08 µm5.59 µm

Largest among catalog designs · largest in its family

Site pitch, y 5.59 µm — higher than 100% of catalog designs and 100% of its family (the largest in its family, 9 designs)
Site outline area
72.08 mm²
0.026 mm²970.7 mm²

Top 31% of catalog designs

Site outline area 72.08 mm² — higher than 69% of catalog designs and 78% of its family
Neural interface volume
40.56 mm³
0.228 mm³501.1 mm³

Top 31% of catalog designs

Neural interface volume 40.56 mm³ — higher than 69% of catalog designs and 78% of its family
Site coverage density
0.194 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 84% of catalog designs

Site coverage density 0.194 sites/mm² — higher than 16% of catalog designs and 11% of its family
Brain coverage density
0.345 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 84% of catalog designs

Brain coverage density 0.345 sites/mm³ — higher than 16% of catalog designs and 11% of its family
EEG 16-Channel GridSKU grd_eeg--eeg_r_16_cl10_func

5 notes · What removing the craniotomy changes · Where the difficulty moves: alignment and fixation · Coverage and site layout …

EEG 16-Channel GridSKU grd_eeg--eeg_r_16_cl10_func

18 links · Choosing an Electrode for Your Experiment · Thin-Film Grids for Surface Recording · Care, Use and Handling …

EEG 16-Channel GridSKU grd_eeg--eeg_r_16_cl10_func

Cited in 74 publications (product line)
