Grids · EEG Series

EEG 16-Channel Grid

16Sites
12µmThickness
7.5mmWidth
196,350µm²Site Area
Part no.Eeg-m-16-cl10
Contents

16-site EEG grid, 7.5 × 8.1 mm

A thin polyimide film that sits on the outside of the skull, with no bone removed and no dura opened, carrying large sites that average a broad patch at low impedance. Among the 55 grid designs in the design space it is mid-range: 17 sites (27th percentile), a 8.1 mm site-array span (62nd percentile), 0.28 sites/mm² (20th percentile) and a 34 mm³ neural interface (60th percentile).

Orders as a grid-plus-package assembly, in 6 package configurations, 3 of them microdrive-compatible. Polyimide 12 µm thick. Research use only.

Also known as

eeg_mouse_16_10

EEG 16-Channel GridSKU grd_eeg--eeg_m_16_cl10

10 specs

Channels16
Site layoutGrid
Site area196,350 µm²
Span8100 µm
SubstratePolyimide
Site materialPlatinum
Thickness12 µm
Neural interface volume34.400 mm³ (higher than 60% of 55 designs)
Site coverage density0.3 sites/mm² (higher than 20% of 55 designs)
Brain coverage density0.5 sites/mm³ (higher than 22% of 55 designs)
EEG 16-Channel GridSKU grd_eeg--eeg_m_16_cl10

Narrow the options with the filters or pick a card, then add the configuration to your cart. When your cart is complete, get pricing, lead time and usage details in one request; we reply within one business day.

6 options

Configure

Compatible Package
All
H16 — 16-ch Omnetics
H16 (21 mm cable) — 16-ch Omnetics
HC16 — 16-ch Omnetics
HZ16 — 16-ch Hirose
MRH16 — 16-ch Omnetics
X3_H16 — 16-ch Molex

Your selection

16-channel thin-film EEG grid — 12 μm, H16
H16
Compatible Package: H16 — 16-ch Omnetics
SKUgrd_eeg--eeg_m_16_cl10.12um.h16
An application scientist replies within one business day: fit for your prep, usage details, lead time and pricing.

Options

6 of 6
EEG 16-Channel GridSKU grd_eeg--eeg_m_16_cl10

Loading the compatible products…

EEG 16-Channel GridSKU grd_eeg--eeg_m_16_cl10

9 metrics

Each track spans the smallest to the largest value across catalog designs. The band is the range within its family, and the dot is this design's value. “Top N%” is a rank: how many designs have a larger value.

Sites
17
3256

Top 73% of catalog designs

Sites 17 — higher than 27% of catalog designs and 33% of its family
Span, x
7.5 mm
0.1 mm36.5 mm

Top 35% of catalog designs

Span, x 7.5 mm — higher than 65% of catalog designs and 56% of its family
Span, y
8.1 mm
0.26 mm79 mm

Top 38% of catalog designs

Span, y 8.1 mm — higher than 62% of catalog designs and 44% of its family
Site pitch, x
1.75 µm
0.15 µm6 µm

Top 40% of catalog designs

Site pitch, x 1.75 µm — higher than 60% of catalog designs and 44% of its family
Site pitch, y
1 µm
0.08 µm5.59 µm

Top 44% of catalog designs

Site pitch, y 1 µm — higher than 56% of catalog designs and 22% of its family
Site outline area
60.75 mm²
0.026 mm²970.7 mm²

Top 35% of catalog designs

Site outline area 60.75 mm² — higher than 65% of catalog designs and 67% of its family
Neural interface volume
34.4 mm³
0.228 mm³501.1 mm³

Top 40% of catalog designs

Neural interface volume 34.4 mm³ — higher than 60% of catalog designs and 33% of its family
Site coverage density
0.28 sites/mm²
0.066 sites/mm²134.5 sites/mm²

Top 80% of catalog designs

Site coverage density 0.28 sites/mm² — higher than 20% of catalog designs and 22% of its family
Brain coverage density
0.494 sites/mm³
0.128 sites/mm³61.01 sites/mm³

Top 78% of catalog designs

Brain coverage density 0.494 sites/mm³ — higher than 22% of catalog designs and 33% of its family
EEG 16-Channel GridSKU grd_eeg--eeg_m_16_cl10

5 notes · What removing the craniotomy changes · Where the difficulty moves: alignment and fixation · Coverage and site layout …

EEG 16-Channel GridSKU grd_eeg--eeg_m_16_cl10

19 links · Mouse EEG Electrodes and Grids · EEG Recording in Mice: Electrode Options · Surgical Guide: Thin Film Grids - EEG Implantation …

EEG 16-Channel GridSKU grd_eeg--eeg_m_16_cl10

Cited in 74 publications (product line)
