EEG 30-Channel Grid
Recorded from outside the skull, no craniotomy — resolution traded for a preparation that lasts months
12 µm polyimide EEG arrays for the skull surface, no craniotomy; 6 to 32 sites for mouse and rat.
SKU grd_eeg--eeg_m_30_a_cl7 · Grids in the webstore
Specifications
| Channels | 30 |
|---|---|
| Site layout | Grid |
| Site area | 196,350 µm² |
| Span | 8757 µm |
| Substrate | Polyimide |
| Site material | Platinum |
| Thickness | 12 µm |
| Neural interface volume | 34.412 mm³ (higher than 66% of 56 designs) |
| Site coverage density | 0.5 sites/mm² (higher than 39% of 56 designs) |
| Brain coverage density | 0.9 sites/mm³ (higher than 41% of 56 designs) |
