EEG 30-Channel Grid
30-channel thin-film EEG grid
12 µm polyimide EEG arrays for the skull surface, no craniotomy; 6 to 32 sites for mouse and rat.
eeg_mouse_30_a_10 · Mouse EEG_v2-X3 · mouse_eeg_v2_x3 · Mouse EEG_v2-HZ32 · mouse_eeg_v2_hz32
10 specs
| Channels | 30 |
|---|---|
| Site layout | Grid |
| Site area | 196,350 µm² |
| Span | 8757 µm |
| Substrate | Polyimide |
| Site material | Platinum |
| Thickness | 12 µm |
| Neural interface volume | 34.412 mm³ (higher than 65% of 55 designs) |
| Site coverage density | 0.5 sites/mm² (higher than 40% of 55 designs) |
| Brain coverage density | 0.9 sites/mm³ (higher than 42% of 55 designs) |
